Design of Monitoring Alarm System Based on GPRS MMS

Abstract:

This system based on embedded technology, MMS wireless communication, etc. Various kinds of modern technology, design a kind of based on GPRS MMS remote monitoring alarm system, this system chooses LPC2132 chip as embedded processor, serial ports, camera, GPRS and infrared pyroelectric sensor module and other hardware. Main funtions as follows: when someone illegally broken into specific space abnormal happens, infrared pyroelectric sensor embedded processor immediately trigger caused disruption, the camera automatically shooting scene image, and transferred to the embedded processor module, embedded processor calls AT instructions through GPRS networks will the collected pictures sent to specify users mobile phone. Users can call or send messages to the system for pictures, but also through the mobile terminal control the system protection and removal. System software embedded in part using development platform ADS development, the key technology was embedded processor interrupt trigger, user instruction processing, control the acquisition and sending MMS etc. This paper analyses the working principle, AT GPRS directive system structure of use, embedded in space, thus realize user of real-time monitoring and alarm.

• Periodical: Advanced Materials Research (Volumes 1049-1050)
• Pages: 2149-2152
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1049-1050.2149
• Online since: October 2014
• Authors: Yong Qi Han*, Li Ma, Hong Liang Guo
• Keywords: Embedded System, GPRS, Monitoring, Multimedia Messaging Service

References

[1] Chu C A, Chen Y T. Research of Remote Monitoring Based on Embedded System and GPRS[J]. Applied Mechanics and Materials, 2013, 241: 2228-2232.

DOI: 10.4028/www.scientific.net/amm.241-244.2228

[2] Samuel C P J, Prakash S, Kumar M A, et al. ZigBee Based Home Security Alert System: An Integrated Approach[J]. Journal of Artificial Intelligence, 2013, 6: 89-94.

DOI: 10.3923/jai.2013.89.94

[3] Li C, Su J. Design and Realization of Infrared Sensor Monitoring System Based on Double MCU[C]. Computational and Information Sciences (ICCIS), 2013 Fifth International Conference on. IEEE, 2013: 1505-1508.

DOI: 10.1109/iccis.2013.396

[4] Hou X Q, Wang X D. Wireless Data Transmission Based on GPRS in Greenhouse Monitoring System[J]. Applied Mechanics and Materials, 2013, 303: 2054-(2057).

DOI: 10.4028/www.scientific.net/amm.303-306.2054

[5] He Y, Li Y, Yin C. Falling-incident detection and alarm by smartphone with Multimedia Messaging Service (MMS)[J]. E-Health Telecommunication Systems and Networks, 2012, 1(01): 1.

DOI: 10.4236/etsn.2012.11001
