Design of an Analog Control Circuit for the Automatic Sun-Tracking PV Bracket System

Abstract:

This paper designed an analog control circuit which can automatically track the sun for PV bracket system to improve the solar cell photo-electricity conversion efficiency. The sunlight intensity can be real-time detected by sampling the short-circuit current of solar cell. The PV bracket system can be automatically adjusted to achieve a final horizontal angle and pitch angle by using the hysteresis comparator and dedicated motor driver chip, which always makes photovoltaic modules toward the sun's position. At the same time, the PV bracket system can be automatically reset by the hall switch when the sun reaches the sunset and the light intensity is less than the reference value. The experimental prototype is used to testify the correctness and reliability of the control system, which has better practicability and value to extend.

• Periodical: Advanced Materials Research (Volumes 1049-1050)
• Pages: 678-681
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1049-1050.678
• Online since: October 2014
• Authors: Mian Liao*, Ling Yun Kong, Hong Liang Ding
• Keywords: Analog Control Circuit, Automatic Sun-Tracking, Photovoltaic, PV Bracket

References

[1] The 15 national energy technical committee of experts in the field of high-tech development plan, energy research and development strategy [M]. Chemical Industry Press, Beijing, China (2004).

[2] Li Anding. Solar photovoltaic systems engineering[M]. Beijing University of Technology press, Beijing, China (2001).

[3] Han Fei, Pan Yuliang, Su Zhongxian: Study on the design method of optimal angle of fixed photovoltaic panels , Journal of engineering design [J], Vol. 10 (2009), pp.25-29.

[4] Xue Liming; angle photovoltaic bracket of a manual adjustment[P]. China patent, application No. 201220150576(2012).

[5] Zhao Lei; An solar photovoltaic bracket of adjustable angle[P]. China patent, application No. 201310090947(2013).
