Effect of Electro Deposition Parameters on Thickness and Fe Contents of Nickel-Iron Foam Alloys

Abstract:

An Ni-Fe alloy on the surface of nickel foam was prepared by electro deposition. The effects of technological parameters including current density, pH value, temperature and the ratio of [Ni²⁺] to [Fe²⁺] of planting solution on the thickness and iron content of the alloy coating were studied. The cross-section microstructure and surface morphologies were observed by optical microscopy and scanning electron microscope, and the compositions of the alloy coating were analyzed by energy dispersive spectrometer and ICP-AES. Experiment results show that the thickness of the alloy coating is increased with increasing current density, temperature, pH value and the ratio of [Ni²⁺] to [Fe²⁺] of the planting solution. The Fe contents of the alloy coating is increased with increasing current density and pH value of the planting solution, and decreased with increasing temperature and the ratio of [Ni²⁺] to [Fe²⁺] of the planting solution. A 36.2 μm thick alloy layer of uniform and dense coating with the Fe content of 60.5 wt% is obtained under the parameters of n(Ni²⁺)/ n(Fe²⁺)= 4, current density = 10 A/dm² and pH = 4.2 at 50 °C for one hour.

• Periodical: Advanced Materials Research (Volume 1053)
• Pages: 41-49
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1053.41
• Online since: October 2014
• Authors: Xiao Min Huo*, Gang He, Hong Yun Lin, Jian Li Wang, De Qing Wang
• Keywords: Coating Thickness, Co-Deposition, Fe Content, Foam Alloy

References

[1] T. H. Wei, C. Z. Zhang, Z. F. Ping. Technologies and parameters of nickel foam [J]. Chinese Battery Industry. 6(2002): 315-318.

[2] Isao Maatsumoto, et al. USP: 4251603, (1981).

[3] M. Y. Feng, M. L. Jun, C. Z. Xia. A study absorption property of foamed nickel [J]. Noise and Vibration Control. 2(2001): 13, 30-33.

[4] Z. S. Jie. Research on the preparation technology for hydrogen-storage electrode with foam substrate [J]. Chinese Journal of Power Sources. 1(1994): 14-15, 38.

[5] S. Gang, C. Chao, P. Fang, et al. Electrodeposition of Ni and Fe alloy on diamond grains [J]. Surface Technology. 36(2007): 49-51.

[6] Z. Q. Mao, Y. Z. Yang, S. Y. Qin, Ni-Fe alloy electro-plating [J]. Test Technology and Testing Machine. 38(1998): 51-53.

[7] G. Cabello, G. Funkhouser, J. Cassidy, et al. Inhibition by CO of the corrosion of Fe, Ni, and their alloys in concentrated HCl solutions[J]. Electroanalytical Chemistry. 2011, 662: 150-156.

DOI: 10.1016/j.jelechem.2011.05.015

[8] P. Fricoteaux, C. Rousse. Influence of substrate, pH and magnetic field onto composition and current efficiency of electrodeposited Ni-Fe alloys [J]. Electroanalytical Chemistry. 2008, 612: 9-14.

DOI: 10.1016/j.jelechem.2007.08.022

[9] J. H. Kim, T. H. Yim, J. H. Lee. Effects of bath and operating conditions on the composition of Ni-Fe alloy electroplating for solar cell substrate [J]. Current Applied Physics. 13(2013): S108-S110.

DOI: 10.1016/j.cap.2013.01.032

[10] L. M. Ming, Z. D. Yuan, C. Jun , et al. Fabrication and electromagnetic properties of bio-based helical soft-core particles by way of Ni-Fe alloy electroplating[J]. Magnetism and Magnetic Materials. 323(2011): 3223-3228.

DOI: 10.1016/j.jmmm.2011.07.012

[11] A. Ispas, H. Matsushima, A. Bund, et al. A study of external magnetic-field effects on nickel-iron alloy electrodeposition, based on linear and non-linear differential AC electrochemical response measurements [J]. Electroanalytical Chemistry. 651(2011).

DOI: 10.1016/j.jelechem.2010.12.003

[12] D. H. Lin, G. Z. Cheng, L. L. Yan. Effect of heat treatment temperature on microstructure and properties of nanocrystalline Ni-Fe alloy foils prepared by electrodeposition [J]. The Chinese Journal of Nonferrous Metals. 19(2009): 1068-1072.

[13] R. T. Clauss, R. A. Tremmel. Plating. 60(1973): 803.

[14] C. S. Yu, S. X. Qi. New additive –791, brightener for electro-plating Ni-Fe alloy and bright nickel [J]. Electroplating & Pollution Control. 1(1981): 30-32.

[15] Y. Y. Fang, G. Z. Qing, D. L. Yuan, et al. Progress of Ni-Fe alloy plating [J]. Elactroplating & Finishing. 24(2005): 23-27.

[16] M. Bo, L. Bo, W. Y. Hui, et al. Study on deposition of fine Ni-Fe alloy films on Si substrate by pulse electroplate [J]. Micro Fabrication Technology. 2 (2007): 24-27.

[17] D. P. Qiang, C. X. Wen, X. Z. Nan, X. W. Chang. Annealing hardening of nanocrystalline Ni-Fe alloy coatings synthesized by brush plating using soluble anode [J]. The Chinese Journal of Nonferrous Metals. 19(2009): 1252-1256.

[18] G. S. Jiang, L. Y. Dong, X. Dong, et al. Electrodeposition of Fe-Ni alloy coating on ferritic stainless steel[J]. Transaction of Nonferrous Metals Society of China. 20 (2010): s226-s230.

DOI: 10.1016/s1003-6326(10)60044-1

[19] H. Dahms. The influence of hydrolysis on the deposition and co-deposition of iron-group metals (Fe, Co, Ni) at the dropping mercury electrode[J]. Electroanalytical Chemistry. 8(1965): 5-12.

DOI: 10.1016/0022-0728(64)80033-4

[20] H. Dahms, I. M. Croll. The anomalous codeposition of nickel-iron alloys[J]. Electrochem. Society. 112(1965): 771-775.

DOI: 10.1149/1.2423692

[21] Y. Y. Fang, G. Z. Qing, Y. Z. Hui et al. Electrodeposition of bright microcrystalline nichel-iron alloy foil [J]. Journal of South University (Science and Technology). 36(2005): 977-982.

[22] W. D. Qing, L. J. Ling. Electro deposition of nickel on polyurethane foam [J]. Journal of Dalian Jiaotong University. 32(2011): 76-80, 85.
