Modal Analysis Calculation and Simulation of Ramming Chain

Abstract:

In order to solve a problem that the running of ramming chain is unstable and master each order natural frequency and deformation characteristics of the chain, the method of theoretical calculation and finite element analysis with software ANSYS is used on the natural frequency of the calculation and analysis. By comparing the data obtained from two methods to verify the correctness of the finite element model, the model is used to analyze natural frequencies and corresponding vibration mode of the ramming chain. The results show that under the low order natural frequency, the main deformation of the ramming chain is the lateral bending, longitudinal bending and torsion deformation, so the results provide the basis to master the deformation of the chain.

• Periodical: Advanced Materials Research (Volume 1055)
• Pages: 234-237
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1055.234
• Online since: November 2014
• Authors: Peng Cheng Yan, Chi Yu Hao*, Hua Gang Sun, Chao Liu
• Keywords: ANSYS, Finite Element, Modal Analysis, Ramming Chain

References

[1] B.L. Hou, J.M. Qiao, C.M. Liu. Automatic loading of Artillery. Beijing: Weapon Industry Press, 2010: 69-77. (In Chinese).

[2] H.Y. Hu. Mechanical Vibration Foundation. Beijing: Beijing University of Aeronautics and Astronautics Press, 2005. (In Chinese).

[3] J.J. Hu, W.B. Xu, H.X. Zhang et al. Modal Analysis and Modification Design of the VMC-1000 spindle Box. Mechinery Design & Manufacture, 2011, 1: 50-53. (In Chinese).
