Small-Signal Equivalent Circuit Modeling and Controller Design of DC/DC Converter Based on Matlab

Abstract:

The model-building of DC/DC converter is the key to design the control of system. It is important to study DC/DC converter stability and dynamic performance. A small-signal model of buck/boost circuit was built by average state-space. By analyzing the transfer function of buck/boost circuit, a voltage closed-loop feedback system was designed. Building system of simulation circuit in the Matlab, the result of simulation shows the system has a good static and dynamic performance. It verifies the rationality of the mathematical model and control strategy. It verifies the rationality of the mathematical model and control strategy.
