Comparison of Affecting Factors on the Shear Stress Output of Cylinder-Typed MRF Clutch

Abstract:

With the purpose of studying the main influence on the cylinder-typed magneto-rheological fluid (MRF) clutch, the relationship between the output of shear stress and its affecting factors is presented in this paper; through theoretical derivation from the Bingham Model and the cylinder-typed shear model, the stress born by the MRF in the clutch is analysed, and the affecting factors on the clutch is also simulated and verified through experiments. The study shows that as the magnetic field strengthens, the shear stress of the cylinder-typed MRF clutch grows linearly, with proportionality constant at 0.162; the increase of shear rate, relevant to the magnetic field strength, makes little difference to the torque output, with proportionality constant at 0.00026B. The results indicate that mechanical-electrical integration of clutch devices can be achieved through the control of magnetic field output of the electromagnet.

• Periodical: Advanced Materials Research (Volume 1094)
• Pages: 453-457
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1094.453
• Online since: March 2015
• Authors: Hai Feng Ji, Chun Fu Gao*, Xin Sheng He, Guang Zhang
• Keywords: Clutch, Magnetic Field, MRF, Shear Stress

References

[1] Xiaomei, X. & Caimin, Z. Theoretical Studies on the Design of Cylinder-typed MRF Clutch. Mechanical Transmission. 06(2009) 73-75+122.

[2] Zhang Jinqiu , Zhang Jian. Magneto-rheological fluid Preparation and property analysis based on orthogonal experiment method . New Technology & New Process. 3(2010)59—63.

[3] Yuliang, S. & Cunzhi, P. & Shaopu, Y. &Yuhong, S. Design of and Discussion on MRF Clutch. Mechanical Design. 06(2005)21-24.

[4] Jin, H. & Linqing, L. & Changhua, L. Design and Analysis of Cylinder-typed MRF Clutch. Functional Materials. 05(2005) 760-761+764.

[5] Chengye, L. & Kejun, J. & Fengyan, Y. Numerical Analysis of the Flow Field in the Cylinder-typed MRF Brake. Journal of System Simulation. 03 (2011) 628-631.

[6] Jiping Z. & Jiwen, Z. Design and Analysis of Disc-typed MRF Clutch. Journal of Southwest China Normal University (Natural Science Edition). 02 (2008) 136-138.

[7] Hongyun, W. & Yongxian, L. & Huiqiang, Z. Research on the Centrifugal Force of MRF Clutch. Journal of Magnetic Materials and Devices. 03 (2008) 21-24+47.

[8] Xiaomei, X. & Minggang Z. & Caimin, Z. Design and Analysis of MRF Fan Clutch. Construction Machinery. 01(2010) 30-33+7-8.
