Strength Analysis and Construction Optimization of Cab of Smart Sprayer

Abstract:

Using SolidWorks software to build 3D model of the smart sprayer cab, based on ANSYS Workbench collaborative simulation platform, and referring to the regulation inspection items in the static testing method and accepting technical condition of the protective structures on agricultural and forestry tractors. The deformation map was obtained finite element analysis the cab. The cab was optimized using the optimal designing idea. The maximum stress and displacement of the optimized cab under the same loading are obviously decreased, providing the basis for construction optimization.

• Periodical: Advanced Materials Research (Volume 1094)
• Pages: 475-481
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1094.475
• Online since: March 2015
• Authors: Yu Jing He, Jiang Feng Shen, Yong Chang Yu
• Keywords: ANSYS Workbench , Cab, Finite Element Analysis, Solid Works

References

[1] GB/T 19498-2004The static testing method and accepting technical condition of the protectivestructures on agricultural and forestry tractors The Tractor Standardization technical committee press(in Chinese).

[2] Guan Changming, Qian Lijun, Wu Yangnian. FEA for Automobile Brake Pedal[J]. Automobile Science&Technology, 2009, 3: 58-60.

[3] Li Dexin, Lv Jiangtao, Ying Jinchun. The Analysis of Static and Dynamic characteristic for SX360 Type Vehicle Frame[J]. Mechanical Science and Technology, 2002, 21(3): 380-386.

[4] Zhang Tieshan, Hu Jianli, Tang Yun. Dynamic Finite Element Analysis of Light Vehicle Frame[J]. Journal of Nanjing University of Science and Technology, 2001, 25(6).

[5] Tang Yingshi, Li Yang, He Youlang. Static and Dynamic Characteristic Analysis of Dump Frame[J]. Special Purpose Vehicle, 2006(1).

[6] Yan Yue. Analysis of Bus Frame Based on ANSYS[J]. Journal of Liaoning University of Technology(Natural Science Edition), 2008, 28(6).

[7] Ma Guang, Huang Dongming, Wang Zhiming. Static and dynamic emulation analysis on frame structure of farm tricycle[J]. Journal of Zhejiang University(Agriculture and Life Sciences), 2007, 33(5).

[8] Huang Chaoqun, Lai Fei. Modal Analysis and Testing Study on Heavy Truck'S Frame[J]. Journal of Shandong Jiaotong University, 2011, 19(1).
