Transport Critical Current Density and Flux Pinning Enhancement in Nano-Sized PbO and HfO₂ Added (Bi_1.6Pb_0.4)Sr₂Ca₂Cu₃O₁₀ Superconductor

Abstract:

A comparative study on the effect of PbO (10-30 nm) and HfO₂ (60-80 nm) additions on the superconducting properties of (Bi_1.6Pb_0.4)Sr₂Ca₂Cu₃O₁₀ ((Bi,Pb)-2223) superconductor in the bulk form was carried out. The structure and the microstructure of prepared samples were examined by powder XRD and SEM, respectively. The transition temperature T_c and critical current density J_c was determined by standard dc four-probe method. SEM micrographs showed a homogeneous distribution of Pb and Hf in the samples. It was observed that PbO and HfO₂ additions enhanced J_c for all added samples. J_c was the highest for x= 0.05 wt. % of PbO (1130 mA/cm² at 77 K and 1930 mA/cm² at 30 K) and HfO₂ (900 mA/cm² at 77 K and 1760 mA/cm² at 30 K) addition. This study showed that the addition of PbO and HfO₂ nanopowder provided extra flux pinning centers in the (Bi, Pb)-2223. PbO with smaller particle size showed higher J_c compared with HfO₂ which has a larger particle size.

• Periodical: Advanced Materials Research (Volume 1108)
• Pages: 85-90
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1108.85
• Online since: June 2015
• Authors: Nabil A.A. Yahya, Roslan Abd-Shukor*
• Keywords: Coherence Length, Flux Pinning, Nanoparticle, Penetration Depth

References

[1] A.Ghattas, M. Annabi, M. Zouaoui, F. B. Azzouz, M.B. Salem, Flux pinning by Al-based nano particles embedded in polycrystalline (Bi,Pb)-2223 superconductors, Physica C 468(1) (2008) 31-38.

DOI: 10.1016/j.physc.2007.10.006

[2] W. Kong, R. Abd-Shukor, Enhanced electrical transport properties of nano NiFe2O 4-added (Bi1.6Pb0.4)Sr2Ca2Cu3O10 superconductor, J. of Supercond. Nov. Magn. 23(2) (2010) 257-263.

DOI: 10.1007/s10948-009-0524-3

[3] Y. Zhu, Z.X. Cai, R. C. Budhani, M. Suenaga, D.O. Welch, Structures and effects of radiation damage in cuprate superconductors irradiated with several-hundred-MeV heavy ions, Phys. Rev. B 48(9) (1993) 6436-6450.

DOI: 10.1103/physrevb.48.6436

[4] Y. Fukumoto, Y. Zhu, Q. Li, H.J. Wiesmann, M. Suenaga, T. Kaneko, K. Sato, K. Shibutani, T. Hase, S. ayashi, C. Simon, Dimensionality and pinning of magnetic vortices in the c-axis aligned Bi2Sr2CaCu2O8+δ and (Bi,Pb)2Sr2Ca2Cu3O10/Ag tapes irradiated by 5.8-GeV Pb ions, Phys. Rev. B 54(14) (1996) 10210-10217.

[5] P.X. Zhang, L. Zhou, C.S. Li, F.S. Liu, B. Jiang, H.L. Zheng, Z.M. Yu, Y. Feng, Improvement in critical current density and mechanical strength of (Bi,Pb)-2223 tapes, Physica C 412-414(SPEC. ISS.) (2004) 1120-1123.

DOI: 10.1016/j.physc.2004.02.213

[6] R.C. Ma, W.H. Song, X.B. Zhu, L. Zhang, S.M. Liu, J, Fang, J.J. Du, Y.P. Sun, C.S. Li, Z.M. Yu, Y. Feng, P.X. Zhang, Enhanced flux pinning in (Bi,Pb)-2223/Ag tapes by slight Ni doping, Physica C 405(1) (2004) 34-40.

DOI: 10.1016/j.physc.2004.01.013

[7] G.J. Baldha, I.A. Shaikh, D.G. Kuberkar, J.,A. Bhalodia, U.S. Joshi, R.G. Kulkarni, Enhanced flux pinning and critical currents by Hf and Hf-Ca substitution in YBa2Cu3O7 − δ, Cryogenics 35(1) (1995) 61-65.

DOI: 10.1016/0011-2275(95)90427-h

[8] Nasri A-Hamid, R. Abd-Shukor. Effects of TiO2 Addition on the Superconducting Properties of Bi-Sr-Ca-Cu-O System. Journal of Materials Science 35(9) (2000) 2325-2329

[9] R. Mawassi, R. Awad, M. Roumie, M. Kork, I. Hassan, Effect of ZnO nano-oxide addition on the superconducting properties of the (Bi,Pb)2223 phase, Physica C 324 (2011) 241-244.

DOI: 10.4028/www.scientific.net/amr.324.241

[10] A.Ghattas, M. Annabi, M. Zouaoui, F.B. Azzouz, M.B. Salem, Flux pinning by Al-based nano particles embedded in polycrystalline (Bi,Pb)-2223 superconductors, Physica C: Superconductivity 468(1) (2008) 31-38.

DOI: 10.1016/j.physc.2007.10.006

[11] A. Agail, R. Abd-Shukor, R.: Transport current density of (Bi1.6Pb0.4)Sr2Ca2Cu3O10 superconductor added with different nano-sized ZnO, Applied Physics A 112 (2013) 501-506.

DOI: 10.1007/s00339-012-7439-8

[12] W. Bian, Y. Zhu, Y.L. Wang, M. Suenaga, The intermediate phase during (Bi,Pb)2Sr2CaCu2O8+δ to (Bi,Pb)2Sr2Ca2Cu3O10+δ phase transformation, Physica C 248(1–2) (1995)119-126.

DOI: 10.1016/0921-4534(95)00240-5

[13] B.A. Albiss, I.M. Obaidat, M. Gharaibeh, H. Ghamlouche, S.M. Obeidat, Impact of addition of magnetic nanoparticles on vortex pinning and microstructure properties of BiSrCaCuO superconductor, Solid State Comm. 150(33-34) (2010) 1542-1547.

DOI: 10.1016/j.ssc.2010.06.001

[14] W.S. Chiu, S.X. Too, S.N.H. Daud, N.M.A. Rashid, M.Y. Chia, S.A. Rahman, A. Suhaimi Bakar, Z. Aspanut, P.S. Khiew, T.K. Tan, S. Radiman, R. Abd-Shukor, M.A.A. Hamid & C.H. Chia, Synthesis of Iron Oxide (Fe3O4) Magnetic Nanocrystals by Green Chemistry Approach, Sains Malaysiana 43(6) (2014) 941–945

DOI: 10.1016/j.matchar.2015.05.031

[15] S. Mahmud & Z. Din, Using a Pilot Plant to Synthesize ZnO Powder: Particle Characterisation and Marine Toxicity Studies, Sains Malaysiana 43(2) (2014) 261–265
