Experimental Study on High Intensity Magnetic Separator of Coal of Pingdingshan G Unit

Abstract:

Self-made pairs of pole-type magnetic separator using materials of NdFeB. Permanent high gradient magnetic separator do without excitation current, the equipment with low cost, low operating costs, and highlights the advantages of small floor space, etc. Using stainless steel nets as a poly-magnetic medium, we conducted a dry separation experimental study on high-sulfur coal of Pingdingshan G unit, focusing on the vibration frequency; number of sorting and pulverized coal size, and the effect on the separation. The results showed that: the increase in desulfurization rate and ash removal rate is based on the cost of losses of clean coal yield. When vibration frequency is 50HZ, the pulverized coal with 100-200 mesh through three times sorting, the desulfurization rate and ash removal rate is 28.02% and 22.43%, and the corresponding coal production rate is 80.79%.

• Periodical: Advanced Materials Research (Volumes 113-116)
• Pages: 1849-1855
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.113-116.1849
• Online since: June 2010
• Authors: Hong Guang Jiao, Rui Xia Tian
• Keywords: Ash Fall, Coom, Desulfurization, Dry Coal Preparation, Magnetic Separation, Permanent Magnet

References

[1] Jiao Hongguang, Ding Lianzheng and Chen Qingru. The Development and Thinking on Desulfurization Technology of High Gradient Magnetic Separation of Fine Coal [J]. China Mining Magazine, 2007, 16(6): 79-81.

[2] Chen Qingru, Jiao Hongguang, Pan Lanying, ect. Two Segment Highly-Efficient Pry Preparation Technologies of Steamcoal Pre-combustion [J]. Journal of Henan Polytechnic University (natural science), 2007, 26(4): 345-352.

[3] Zhun Fuhai, Zhu Shenhong. An Experimental Study on HGMS Coal Desulfurization and Ash [J]. Coal Science and Technology, 2005, 33(7): 61-94.

[4] Wang Donglu, Li Yong. Experimental Study of High-Gradient Magnetic Separation Desulfurization [J]. Shandong Electric Power, 2004, 3: 7-11.

[5] Wu Shibin, Zhang Hengjian, Zhang Sijing. An Experimental Study on Dry Magnetic Desulfurization of Pulverized Loal [J]. Environmental Science, 1989, 11(6): 25-28.

[6] C. Cakdjerk so. Mineral Composition and Particle Size Influence on the High-gradient Magnetic Separation of Coal Preparation [J]. The International Electromagnetic Beneficiation and Filtration Technology Conference Proceedings , 1984: 151-153.

[7] Zheng Jian-zhong. Desulfurization of Fine Coal - Coal and Associated Minerals of the Magnetic Susceptibility and High-gradient Magnetic Separation of Coal Desulfurization [D]. Beijing: China University of Mining (Beijing Campus), (1993).

DOI: 10.1201/9781351075589-12

[8] Zhu Shenhong, Yang Weidong, Lou Xingyi. Coal Desulfurization Technology Status and High Gradient Magnetic Separation Technology in the Desulfurization [J]. Journal of Qingdao Institute of Architecture and Engineering. 2001, 22 (1) : 26-19.

[9] Li Yong, Wang Donglu, Shen Jingwei. Technique of High Gradient Magnetic Separation for The Study of Coal Desulfurization [J]. Jilin Electric Power. 2006, 34 (3) : 1-4.

[10] Sun Zhongyuan, Feng Dingwu. Superfine Material Dry-type Vibrating High Gradient Magnetic Separation of Iron Removal [J]. Metallic Ore Dressing Abroad. (1998).

[11] Tang Yuegang and so on. Pyrite in Coal and Its Mechanism of Magnetic [J]. Chinese Science Bulletin, 1995, 8: 1483-1486.

[12] David 8. Kelland. A review of Hgms Methods of Coal Cleaning [J]. IEEE Transactions on Magnetics. 1982, 5，18（3）：841-846.

DOI: 10.1109/tmag.1982.1061940

[13] E.C. Hise, A.S. Holman and F. 3. Friedlaender. Development of High-gradient and Open-gradient Magnet Separation of Dry Fine Coal [J]. IEEE Transactions on Magnetics 1981, 11，17（6）： 3314-3316.

DOI: 10.1109/tmag.1981.1061625
