Study on Sapphire Wafer Grinding by Chromium Oxide (Cr₂O₃) Wheel

Abstract:

Finishing process of sapphire wafer is meeting huge challenge to fulfill the strict requirement of high surface quality in semiconductor industry. Fixed abrasive process, although can guarantee the profile accuracy, leaves damaged layer on the surface or subsurface of sapphire wafer. Chemical mechanical polishing (CMP) is famous for providing great surface roughness, however, sacrifices surface geometrical accuracy. Therefore, a new chromium oxide (Cr₂O₃) sapphire grinding wheel based on chemical mechanical grinding (CMG) principle has been developed and its performance has also been put into examination. The experiment result has demonstrated that Cr₂O₃ possesses an outstanding potential in terms of a high material removal rate of sapphire wafer, meanwhile, largely reduces surface roughness from about 150nm to below 10nm in 1 hour. In addition, the design of experiment (DOE) has also been carried out to study the effect of influencing factors towards ultimate surface roughness of sapphire wafer. It reveals that the revolution speed of sapphire wafer bears twice greater influence towards surface roughness than the revolution speed of grinding wheel.

• Periodical: Advanced Materials Research (Volume 1136)
• Pages: 311-316
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1136.311
• Online since: January 2016
• Authors: Ke Wu*, Naoki Yamazaki, Yutaro Ebina, Li Bo Zhou, Jun Shimizu, Teppei Onuki, Hirotaka Ojima, Takashi Fujiwara
• Keywords: Chemical Mechanical Grinding, Design of Experiment, Material Removal Rate (MRR), Sapphire Wafer, Surface Roughness

References

[1] H. Aida, T. Doi, H. Takeda, H. Katakura, S.W. Kim, K. Koyama, T. Yamazaki, M. Uneda, Ultraprecision CMP for sapphire, GaN, and SiC for advanced optoelectronics materials, Current Applied Physics. 12 (2011) S41–S46.

DOI: 10.1016/j.cap.2012.02.016

[2] J.B. Johnson, D.W. Kim, R.E. Parks, J.H. Burge, New approach for pre-polish grinding with low subsurface damage, Proceedings of SPIE. 8126 (2011) 81261E.

DOI: 10.1117/12.893912

[3] Gutsche H W, Moogy J W, Polishing of sapphire with colloidal silica, Electrochem society of Solid-State Science and technology. 1978: 136-138.

[4] Eda H, Zhou L, Nakano H, Kondo R, Shimizu J, Development of single step grinding system for large scale Φ300 Si wafer, CIRP Annals. 2001, 50(1): 225-8.

DOI: 10.1016/s0007-8506(07)62110-6

[5] Zhou L, Eda H, Shimizu J, Kamiya S, Iwase H, Kimura S, Defect-free fabrication for single crystal silicon substrate by chemo-mechanical grinding, CIRP Annals. 2006, 55(1): 313-6.

DOI: 10.1016/s0007-8506(07)60424-7

[6] Zhou L, Shimizu J, Eda H, Kimura S, Research on chemo-mechanical-grinding (CMG) of Si wafer (2nd report), J Jpn Soc Precis Eng. 2005, 71(4): 466-70.

DOI: 10.2493/jspe.71.466

[7] Taniguchi N. Nanotechnology. Oxford University Press, 1996, pp.58-62.
