Controllability Study of Single-Crystal Diamond Cutting Tool Focus Ion Beam Milling with Different Beam Current and Tilting Angle

Abstract:

Micro/nanoscale diamond cutting tools used in ultra-precision machining can be fabricated by precision grinding, but it is hard to fabricate a tool with a nanometric cutting edge and complex configurations. High-precision geometry accuracy and special shapes for microcutting tools with sharp edges can be achieved by focused ion beam (FIB) milling. However, in the FIB milling process, the surface properties of the substrate (such as a diamond substrate) are affected by the amorphous damage layer caused by the FIB gallium ion collision and implantation and these influence the diamond cutting tool edge sharpness and increase the processing procedure. In this study, to reduce the diamond cutting tool edge sharpness and processing procedure, FIB milling beam current and tilting angle characteristics of single-crystal diamond were investigated, along with method for decreasing the FIB-induced damage on diamond tools by platinum (Pt) coating on the diamond substrate. Experimental results revealed that optimize beam current, tilting angle and platinum (Pt) coating could lead to relatively few processing procedure and sharp cutting tool edge. The obtained results are an endeavor to enhance the controllability of the diamond cutting tool FIB milling.

• Periodical: Advanced Materials Research (Volume 1136)
• Pages: 430-434
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1136.430
• Online since: January 2016
• Authors: Seung Yub Baek*, Woong Kirl Choi, Young Jae Choi, Eun Sang Lee
• Keywords: Beam Current, Diamond Cutting Tool, Edge Sharpness, Focused Ion Beam, Micro/Nanoscale, Tilting Angle

References

[1] W.J. Zong, Z.Q. Li, T. Sun, K. Cheng, D. Li, S. Dong, The basic issues in design and fabrication of diamond-cutting tools for ultra-precision and nanometric machining, J. Mach. Tools Manuf. 50 (4) (2010) 411–419.

DOI: 10.1016/j.ijmachtools.2009.10.015

[2] W. Wu, Z. W. Xu, F. Z. Fang, B. Liu, Y. J. Xiao, J. P. Chen, X. B. Wang, H. Z. Liu, Decrease of FIB-induced lateral damage for diamond tool used in nano cutting, Nucl. Instrum. Meth. B. 330 (2014) 91-98.

DOI: 10.1016/j.nimb.2014.04.005

[3] S. Rubanov, A. Suvorova, Ion implantation in diamond using 30 KeV Ga+ focused ion beam, Diam. Relat. Mater. 20 (2011) 1160-1164.

DOI: 10.1016/j.diamond.2011.06.027

[4] M. Pacella, P. W. Butler-Smith, D. A. Axinte, M. W. Fay, FIB/TEM/EELS micro/nanometric investigations of the effects of laser ablation on the diamond/binder structure in polycrystalline diamond composites, J. Mater. Process. Tech. 214 (2014).

DOI: 10.1016/j.jmatprotec.2013.10.007
