Development of Direct Drive Motor for Machine Tools and its Performance in Machining

Abstract:

This paper describes the development of a direct drive motor (DD motor) without a reduction gear for the rotary motion of machine tools and its performance. We investigate novel DD motors from a view of total performance on machine tools. Moreover, we estimate to employ the developed DD motors for 5-axis control machine tools and the multi-functional machine tools. The study proves the required performance of rotary motion is achieved on machine tools, and the developed DD motors are found to be effective as follows. First, designing a DD motor with quality engineering and FEM analysis of electro-magnetic field is found to be effective for a low cogging torque and a low torque ripple. It is demonstrated that the developed DD motor makes it feasible to generate the excellent surface roughness on the complex shape workpiece with a ball-nose endmill tool, compared with the machined surface roughness by a conventional rotary axis with a reduction gear. Second, a maximum angular velocity of the DD motor is balanced with a maximum velocity of the linear axis, but a maximum angular acceleration of the DD motor is not balanced enough with a maximum acceleration of the linear axis. Therefore, the angular acceleration is needed to be improved as a next step.

• Periodical: Advanced Materials Research (Volume 1136)
• Pages: 661-666
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1136.661
• Online since: January 2016
• Authors: Takakazu Ikegami*, Toshiki Hirogaki, Eiichhi Aoyama
• Keywords: Direct Drive Motor, Linear Axis, Machine Tools, Machined Surface Roughness, Machining, Rotary Axis

References

[1] J. Francis Reintjes, Numerical control(Making a New Technology), Oxford University Press, (1991)66-72.

[2] Makoto SATO, 5MC Structure and its Types, Proc. of 16th International Machine Tool Engineers' Conference(2007)pp.184-186 (in Japanese).

[3] Yutaka ONO，Control of DD motor and its Feature，Journal of the Robotics Society of Japan，Vol. 7, No. 3（1989）254-259（in Japanese）.

[4] Yukihiro OKADA, et. al, Optimization of Interior Permanent Magnet Motor by Quality Engineering and Multivariate analysis, IEEJ Trans IA, Vol. 123, No. 12(2003)1516-1522（in Japanese）.

DOI: 10.1541/ieejias.123.1516

[5] N. MURAKAMI, Feature of 5-axis Machining Center and Its Applications, Bulletin SOKEIZAI, Vol. 48, No. 3(2007)pp.18-23 (in Japanese).

[6] Kaoru YASUMATSUYA, Tatsuya YAMAMOTO, High-Speed, High-Precision, 5-AxisControl Horizontal Machining Center with Direct Drive Motor，Annals of The Japan Society for Precision Engineering Spring Lecture(2008)589-590（in Japanese）.
