The Effect of Thickness on the Magnetic Anisotropy and Magnetic Properties of Single-Layered FePt Films by In Situ Annealing

Abstract:

The FePt films with various thicknesses of 5 to 50 nm are deposited on Si(100) substrate without any underlayer by in-situ annealing at substrate temperature (Ts) of 620°C. A strong (001) texture of L10 FePt film is obtained and presents high perpendicular magnetic anisotropy as the film thickness increases to 30 nm. Further increasing the thickness to above 30 nm, the (111) orientation of L10 FePt is enhanced greatly, indicating that the quality of perpendicular magnetic anisotropy degrades when the FePt film is thicker than 30 nm. The single-layered FePt film with thickness of 30 nm by in-situ depositing at 620°C shows good perpendicular magnetic properties (perpendicular coercivity of 14.0 kOe, saturation magnetization of 473 emu/cm3 and perpendicular squareness of 0.96, respectively), which reveal its significant potential as perpendicular magnetic recording media for high-density recording.

You might also be interested in these eBooks

Multi-Functional Materials and Structures III

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 123-125)

Pages:

507-510

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.123-125.507

Citation:

Cite this paper

Online since:

August 2010

Authors:

Sheng Chi Chen, T.H. Sun, C.L. Chang, Chih Long Shen, G.P. Lin, K.T. Huang, S.L. Ou, Po Cheng Kuo

Keywords:

Film Thickness, In Situ Annealing, Perpendicular Magnetic Anisotropy, Single-Layered FePt Films

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] O.A. Ivanov, L.V. Solina, V.A. Demshina and L.M. Magat: Phys. Met. Metallogr. Vol. 35 (1973). p.81.

Google Scholar

[2] D. Weller, A. Moser, L. Folks, M.E. Best, W. Lee, M.F. Toney, M. Schwickert, J.U. Thiele and M.F. Doerner: IEEE Trans. Magn. Vol. 36 (2000), p.10.

DOI: 10.1109/20.824418

Google Scholar

[3] Y.G. Peng, J.G. Zhu and D.E. Laughlin: J. Appl. Phys. Vol. 99 (2006), p. 08F907.

Google Scholar

[4] Y. Xu, J.S. Chen and J.P. Wang: Appl. Phys. Lett. Vol. 80 (2002), p.3325.

Google Scholar

[5] J.S. Chen, B.C. Lim, Y.F. Ding, J.F. Hu, G.M. Chow and G. Ju: J. Appl. Phys. Vol. 105 (2009), p. 07B702.

Google Scholar

[6] M.F. Toney, W.Y. Lee, J.A. Hedstrom and A. Kellock: J. Appl. Phys. Vol. 93 (2003), p.9902.

Google Scholar

[7] B.D. Cullity: Elements of X-ray Diffraction, second edition, Massachusetts: Addison-Wesley (1978).

Google Scholar

[8] Y. Huang, H. Okumura, G.C. Hadjipanayis and D. Weller: J. Magn. Magn. Mater. Vol. 242-245 (2002), p.317. (a) (b) (c) (d).

Google Scholar
