A Variant Design Method of Assembly

Abstract:

To improve the design efficiency of product, the variant design method of assembly is researched. Firstly, the identifying and extracting method of assembly constraints is researched, and an identifying and extracting method of assembly constraints based on the re-development technology of SolidWorks is presented. With the identifying and extracting method, assembly constraints are obtained and a relationship network of them is built. Secondly, a method for dimensions to transfer around the relationship network of assembly constraints is researched and a dimension transfer method is put forward. Then a dimension modify method of assembly based on the dimension transfer method is obtained. Lastly, a variant design method of assembly based on the dimension transfer and dimension modify method is presented and a variant design module integrated into SolidWorks is developed. As an example, all methods are applied to a coupling assembly, and the methods are verified.

• Periodical: Advanced Materials Research (Volumes 139-141)
• Pages: 1126-1130
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.139-141.1126
• Online since: October 2010
• Authors: Fu Yun Liu, Ni Ya Lu, Bing Kuang
• Keywords: Assembly, Assembly Constraint, Variant Design

References

[1] Yu Junhe, Qi Guoning. Study on the Method of Variant Design Based on SML[J] Transactions of The Chinese Society of Agricultural Machinery, Vol 36(2005), p.107.

[2] Wu Weiwei, Tang Rongzhong, Hou Liang, et al. Research & Realization on the Variant Design of Mechanical Products Based on Parametric Techniques[J]. China Mechanical Engineering, Vol 16(2005), p.218.

[3] Yu Junhe. Research on the Implementation Method of Object-Oriented SML[J]. China Mechanical Engineering, Vol 16(2005), p.878.

[4] ALEXANDER F, GERHAND F, DIET MAR J. Conceptual modeling for configuration of mass customizable products [J]. Artificial Intelligence in Engineering, Vol 15(2001), p.65.

[5] Xiao Xinhua, Shi Minghua, Yang Xiaofen, et al. Research on variant design based modular product case[J]. China Mechanical Engineering, Vol 18(2007), p.803.

[6] DENG Xiao-lin, LIU Fu-yun. Part variant design methods based on parametric technology[J]. Machine design and research, Vol 24(2008), p.82.

[7] Xu Xin-sheng, Fang Shui-liang, Li Qiang, et al. Research on assembly variant design[J]. Journal of Zhejiang University(Engineering Science), Vol 40(2006), p.1652.

[8] LIU Fuyun, QI Guoning. Dimension parameters transfer method of configuration product and its application[J]. Chinese Journal of Mechanical Engineering, Vol 43(2007), p.144.

DOI: 10.3901/jme.2007.04.144

[9] LIU Fu-yun DENG Xiao-lin. Dimesion parameter modification and variant design method of configuration product[J]. Computer integrated manufacturing systems, Vol 14(2008), p. (2092).

[10] Lu Changming, Zhang Libin, Jiang Jiandong, et al. Rapid variant design approach based on design template[J]. Transactions of The Chinese Society of Agricultural Machinery, Vol 40(2009), p.197.

[11] SAMBHOOS Kedar, KOC Bahattin, NAGI Rakesh. Extracting Assembly Mating Graphs for Assembly Variant Design[J]. Journal of computing and information science in engineering, Vol 9(2009), p.034501. 1.

DOI: 10.1115/1.3184607

[12] Kai Cheng, Yongxian Liu, Xipeng Xu. Dimension Parameter Transfer Method Based on Constraint Satisfaction Priority in variant design[J]. Applied Mechanics and Materials, Vol 1619(2009), pp.203-207.

DOI: 10.4028/www.scientific.net/amm.16-19.203
