Research on Drive Control Method of Scanning Mechanism of Radar Scatterometer Antenna

Abstract:

A set of drive control system has been developed for the scanning drive system of radar scatterometer antenna, according to the requirements of its scanning motion for speed stability with three-phase AC permanent-magnet synchronous motor(PMSM) driven by sine wave current as the execute component. The system can achieve the aim of controlling motion trace. The system composition, matching design of characteristic parameters such as speed and torque as well as control realization method, are described in this paper and the testing of main system performances such as speed stability is also briefly introduced. It is shown from the simulation and test that the designed system can complete the control of motion track with speed ability of up to 0.5% and can satisfy the given index requirements.

• Periodical: Advanced Materials Research (Volumes 139-141)
• Pages: 1605-1611
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.139-141.1605
• Online since: October 2010
• Authors: Shao Xiong Zhai
• Keywords: Drive Control, Scanning Mechanism, Speed Stability

References

[1] Li Huade and et al., AC Motor Speed Regulated System [M], Beijing: Publishing House of Electronics Industry, 2002. (In Chinese).

[2] Zhang Haigen and et al., Mechanical and Electrical Transmission Control [M], Beijing: China Higher Education Press, 2001. (In Chinese).

[3] Zhang Chen, Principle of DC Brushless Motor and Application [M], Beijing: Machinery Industry Publishing House, (2004).

[4] Dong Xingzhong, Mechanical and Electrical Transmission Control [M], Wuhan: Huazhong University of Science and Technology Press, (2003).

[5] Chanwoo Moon; Sungho Lee; Chung, J.K.; Hagyoeng Sung. Precise position control of a linear stage integrated with an inchworm type actuator. SICE 2004 Annual Conference Volume 1, 4-6 Aug, 2004 Page(s): 572 - 576 vol. 1.

[6] Jayasoma, S.; Dodds, S.J.; Perryman, R. An FPGA implemented PMSM servo drive: practical issues. Universities Power Engineering Conference, 2004. UPEC 2004. 39th International Volume 1, 6-8 Sept. 2004 Page(s): 499 - 503 Vol. 1.

[7] Ma Zhiyuan, Electric Drive Control System, Beijing: Science Press, 2004. 3. (In Chinese).

[8] Chen Jian, Power Electronics-Power Electronic Conversion and Control Technology (second edition), Beijing: China Higher Education Press, 2004. 12. (In Chinese).

[9] Xue Qing, Huan Yinqun, Cheng Guanggui and Li Jian: Research on High Performance AC Servo Control System Based on PMSM, Science Technology and Engineering, January of (2009).
