Design and Analysis of Automatic Cutting Robot for Vertical-Pull Glass Pipe

Abstract:

By study on the current domestic cutting technics of vertical-pull glass pipe, in this paper a new and practical design of automatic cutting robot is peoposed. Its motion process is introduced on the basis of performance requirement, and then the overall structure of automatic cutting robot for vertical-pull glass pipe is designed, especially the electro-hydraulic proportional control systems for frame rotation and fuselage lifting. Meanwhile the stability and respond speed of hydraulic systems is well analyzed with matlab software. The results of open-loop bode diagram of the frame rotation system and unit step response diagram of fuselage lifting system indicate that the automatic cutting robot has excellent system stability and respond speed. It can content the requirement of position accuracy, reduce the labor intensity with high productivity and liberate the workers from wicked environment.

• Periodical: Advanced Materials Research (Volumes 139-141)
• Pages: 1597-1600
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.139-141.1597
• Online since: October 2010
• Authors: Xiu Hua Sui, De Jun Miao, Zheng Mao Feng
• Keywords: Cutting Robot, Design, Stability, Vertical-Pull

References

[1] M. Owens and D. Clark: the Design and Control of Robot (Scientific Press, Beijing 2004). (In Chinese).

[2] Z.X. Zhang and M. Liu: Machine Design & Research, (2006) No. 3, pp.97-100. (In Chinese).

[3] C.X. Wang: Hydraulic Control System (China Machine Press, Beijing 2000). (In Chinese).

[4] R.W. Yu: Matlab Basic and Applied (China Machine Press, Beijing 2003). (In Chinese).

[5] L. Sun: Matlab Language and Control System Simulation (Beijing Industrial University Press, Beijing 2004). (In Chinese).
