Modeling and Analysis for Sound Field of Rectangular Small Enclosure under the Excitation of Panel Loudspeaker by Using FEM

Abstract:

This paper aims to simulate the sound field of rectangular small enclosure excited by panel loudspeaker with FEM. Firstly, in order to testify the fluid-structure interaction theory in the field of acoustics calculation, coupled modal and uncoupled modal of loudspeaker and air were established. Result of harmonic response analysis shows that the vibration amplitude of uncoupled case is larger than the coupled case. The result just is in harmony with the fact. So when modeling the sound field, fluid-structure coupling should be taken into account. Secondly, for more accurate sound field simulation, different from most researchers’ modeling method that supposing the vibrating plate’s boundary of the loudspeaker is simply supported, this paper provide a more practical way that the boundary is elastic supported. The comparison shows that the resonance of air in enclosure is more severe under elastic boundary on condition of same driving force. Thereby the sound pressure is higher.

• Periodical: Advanced Materials Research (Volumes 139-141)
• Pages: 1985-1989
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.139-141.1985
• Online since: October 2010
• Authors: Bing Fang, Run Jie Shen, Ji Feng Guo, Wen He, Ming Ma
• Keywords: Finite Element Model (FEM), Fluid-Structure Coupling, Modeling, Panel Loudspeaker, Small Enclosures, Sound Field

References

[1] J.L. XIE, S. YANG and J.G. ZHANG. The Response Prediction of the Spacecraft under Acoustic Vibration Environment [J]. Spacecraft Environment Engineering, Vol. 23 (2006) No. 2, pp.83-85. (In Chinese).

[2] B. Fang, R.J. Shen and W. He. Research Summary of The Multiparameter Combined Environmental Test of The reliability of Spacecraft Component[J]. China Mechanical Engineering, Vol. 20 (2009) No. 22, pp.2766-2771. (In Chinese).

[3] Shannon P. McCall, Brian.S. Hardy and R.L. Williams. A Combined Environments Facility for Testing of Space Shuttle External Tank Ice Ball Debris Liberation[R]. AIAA 2008-6914, El Segundo: The Aerospace Corporation.

DOI: 10.2514/6.2008-6914

[4] H.L. ZHANG. Theoretical Acoustics[M]. Bei jing. Higher Education Press, 2007. (In Chinese).

[5] Y.H. LIU: Wave Propagation Study Using Finite Element Analysis (MS., University of Illinois at Urbana-Champaign, America 2005)pp.9-11.

[6] Rong Z. Gan, Q.L. Sun and B. Feng. Acoustic-structural Coupled Finite Element Analysis for Sound Transmission in Human Ear-Pressure Distributions[J]. Medical Engineering&Physics, 2006, 28, pp.395-404.

DOI: 10.1016/j.medengphy.2005.07.018

[7] ANSYS Theory Reference 00855: 9th ed. -Release 5. 4, 1997b, SAS IP, Inc., Canonsburg, PA.

[8] R. WANG and Y.F. ZHANG. Study on the Sound Radiation Characteristics of Panel Loudspeaker[J]. Transactions of Beijing Institute of Technology, Vol. 27 (2007) No. 5, p.377380. (In Chinese). * Corresponding author.
