The Design and Study of Roller Curvature for the Tube or Bar Straightener

Abstract:

The straightener roll should be in contact with the tube or bar in line during the working process. The traditional calculation method using roll-shape curve equation was extremely complex, so this paper presents a new method of determining roll-shape curvature in the condition of the tube or bar contacted with roller in line. By comparison, this calculation method is simple and easy. Moreover, this method guarantees the quality of product with the required accuracy. This method presents a new way in straightener roller design.

• Periodical: Advanced Materials Research (Volume 145)
• Pages: 394-398
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.145.394
• Online since: October 2010
• Authors: Da Chao Hu, Hao Min Chen
• Keywords: Calculation of Parameters, Straightener, Study of Roll-Shape

References

[1] F. Cui: Straightening Principle and Straightening Machine. (Metallurgical Industry Press, China 2005).

[2] Z.L. Liu: Mechanical Design and Manufacturing, Vol. 172 (2005) No. 6, p.25.

[3] C.C. Jiao, Q. Z. Li: Metallurgical Equipment, Vol. 151 (2005) No. 3, p.26.

[4] Z. He, H.H. Hu and J. Zheng: Machinery, Vol. 28 (2001) No. 6, p.58.

[5] G.F. Zhou, J.J. Cao: Shanxi University of Technology, Vol. 23 (2005) No. 3, p.93.

[6] H.R. Liu, Q. Li: Steel Tube, Vol. 91 (1995) No. 4, p.27.

[7] G.Q. Yuan, F.F. Wu: Shandong University of Technology, Vol. 29 (1999) No. 5, p.427.
