Design Method for Braiding Process and Structure Parameters of Three Dimensional Two-Step Tubular Braided Preform

Abstract:

The properties of composites reinforced by three dimensional braided preform are determined by braiding structure significantly. The main objective of this paper is to develop a general methodology for the determination of the design and analysis of three dimensional two-step braided tubular preform. The arrangement pattern of axial yarns with various finenesses is derived for the uniform braiding structure of preform, which offers a possibility for achieving preferable interior structures of braided tubular preforms. Then, the general structure parameters, including the interrelation between surface braiding angles and interior braiding angles and the fiber volume fraction, are investigated in some detail. The results derived from this paper can provide a useful method for the design of 3D two-step tubular braided preform.

• Periodical: Advanced Materials Research (Volumes 150-151)
• Pages: 1613-1616
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.150-151.1613
• Online since: October 2010
• Authors: Yan Gao, Jia Lu Li
• Keywords: Braiding Process, Structure Parameter, Tubular Braided Preform, Two-Step Braiding

References

[1] L. Chen, X. M. Tao, C. L. Choy: Composites Science and Technology No. 59(1999), P. 391.

[2] Jiao Yanan, Li Jialu, Li Xueming: FRP/CM No. 3 (2000), P. 27.

[3] Y. Q. Wang, A. S. D. Wang: Composites Science and Technology No. 54(1995), P. 359.

[4] Li Jialu, Sun Ying : Acta Materiae Compositae Snica Vol. 19, No. 4( 2002), P. 69.
