Effect of Concrete-Filled in Chord Tubes on Mechanical Behavior of RHS Steel Tube Trusses

Abstract:

Based on the experimental results, this paper presents the effects of concrete-filled in chord on the static behavior of rectangular hollow section (RHS) steel tubular trusses, including failure modes, load bearing capacity and structural stiffness. Failure of RHS trusses occurs at joints wether concrete-filled in chord or not, concrete-filled in chord changed the failure mode. Load bearing capacity and stiffness of joints subjected to compression load increased significantly, while it is limited to the tension joints. Concrete-filled in the compression chord tube can increase its stiffness significantly, while tension chord tube, it is not that obvious. Finally, based on the results discussed, failure modes and their formulas of calculating the load bearing capacity are discussed. Meanwhile, two methods, that is, amplified factor method and stiffness discounting method, which calculate the structural displacement when considering the joint deformation effects are presented.

• Periodical: Advanced Materials Research (Volumes 163-167)
• Pages: 2171-2175
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.163-167.2171
• Online since: December 2010
• Authors: Jun Ping Liu, Yong Jian Liu, Jian Yang
• Keywords: Chord Tube, Concrete-Filled, Deformation Amplification Factor, Load-Bearing Capacity, Rectangular Hollow Section Steel Tube, Stiffness Reduction, Truss

References

[1] J.A. Packer, J.E. Henderson. Design guide for steel hollow sections structural joints. Translated by J.J. CAO. Beijing: Science Press, (1997). (In Chinese).

[2] J. Wardenier. Hollow sections in structural applications. Australia: John Wiley & Sons, (2001).

[3] J.A. Packer. Concrete-Filled HSS Connections. Journal of Structural Engineering, Vol. 121(3) (1995), pp.458-467.

DOI: 10.1061/(asce)0733-9445(1995)121:3(458)

[4] Y.J. LIU. Experiments on Ultimate Load bearing capacity and Research on Design Method of Joints of Concrete-filled Rectangular Steel Tube Truss. Changsha: Hunan University, (2003). (In Chinese).

[5] GB 50017. Code for design of steel structures(2003) (In Chinese).

[6] CECS159. Technical Specification for Structures with Concrete-Filled Rectangular Steel Tube Members (2004). (In Chinese).

[7] J.P. LIU. Research on Mechanical Behavior and Design Method of Rectangular Steel Tube Truss with Chord Concrete-inside. Xi'an: Chang'an University, (2009). (In Chinese).

[8] Y.J. LIU, J.P. LIU, G.J. YANG, et al. Experimental research on RHS trusses with concrete-filled chord members. Journal of Building Structures, Vol. 30(6) (2009), pp.107-112. (In Chinese).

[9] Y.J. LIU, J.P. LIU, G.J. ZHANG. Experimental research on RHS and CHS truss with concrete filled chord. Journal of Building Structures, Vol. 31(4) (2010), pp.87-93. (In Chinese).

[10] J.P. LIU, Y.J. LIU. Research on influence of chord concrete-inside on overall stiffness of rectangular hollow section steel tube truss girder. Journal of Building Structures, Vol. 32(suppl. 2) (2009), pp.202-207. (In Chinese).
