Loading Capacity of Simply Supported Steel-Concrete Composite Slim Beams

Abstract:

A steel-concrete composite slim beam, with its steel section encased in a concrete slab, provides a composite steel-concrete floor construction with minimum depth and high fire resistance. It has become popular in multi-storey steel buildings throughout Europe in recent years and also been used in some projects in China. For the structural engineer, it is critical to understand the behavior of composite slim beam in the sagging moment region. In this paper, the bending capacity and flexural stiffness of the composite slim beams in sagging moment region are investigated theoretically. Meanwhile, the stiffness and bending capacity are given by Finite Element Analysis (FEA). The experiment of a simply supported beam has been carried out in order to validate the theoretical results.

• Periodical: Advanced Materials Research (Volumes 163-167)
• Pages: 2185-2193
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.163-167.2185
• Online since: December 2010
• Authors: Lu Yang, Yuan Qing Wang, Yong Jiu Shi
• Keywords: Composite Slim Beam, Experimental Investigation, Finite Element Analysis (FEA), Loading Capacity

References

[2] Lawson, R.M., Bode, H., Brekelmans, J.W.P.M., Wright, P.J. and Mullet, D.L. Slimflor and slimdek construction: European developments. The Structural Engineer, 1997, 77(8): 28-32.

[3] Lu, X.H., M, Makelainen, P. Parametric Studies on Steel-concrete Composite Beams in Slim Floors. Proceedings of the 1st European Conference on Steel Structures, EUROSTEEL'95, Athens, May, 1995: 18-20.

[4] Mikko Malaska. Behavior of a Semi-continuous Beam-column Connection for Composite Slim floors. Helsinki University of Technology, Helsinki, Finland, (2000).

[5] Bernuzzi, C., Gadotti, F., Zandonini, R. Semi-continuity in slim floor steel-concrete composite systems. Proceedings of the 1995 1st European Conference on Steel Structures, EUROSTEEL'95. Athens, (1995).

[6] Lawson, R.M., Mullett, D.L., and Rackham, J.W. Design of Asymmetric Slimflor, Beams. Proceedings of the 1998 2nd World Conference on Steel in Construction, San Sebastian, (1998).

DOI: 10.1016/s0143-974x(98)80020-5

[7] Tu, Y.X., Tu, Y.Q., and Zhou, Z.H. Applications of composite floor with slim beam to entresol structures. Journal of Harbin Institute of Technology, 2005, 37(2): 248-251. (In Chinese).

[8] Borgogno, W., and Fontana M. Fire safety of slim floor composite slabs with precast prestressed hollow core elements. Stahlbau, 1998, 67(10): 776-784.

DOI: 10.1061/40616(281)67

[9] Makelainen, P., and Ma, Z.C. Fire resistance of composite slim floor beams. Journal of Constructional Steel Research, 2000, 54: 345-363.

DOI: 10.1016/s0143-974x(99)00059-0

[10] Bailey, C.G. The behaviour of asymmetric slim floor steel beams in fire. Journal of Constructional Steel Research, 1999, 50: 235-257.

DOI: 10.1016/s0143-974x(98)00247-8

[11] Lu, X.T., and Zhang, S.M. Numerical analysis of composite slim floor beams in fire. Journal of Harbin Institute of Technology, 2005, 37(2): 442-445. (In Chinese).

[12] Lu, X.T., and Zhang, S.M. Analysis of the temperature distribution in composite slim floor beams subjected to fires. Journal of Harbin Institute of Technology, 2005, 37(2): 446-450. (In Chinese).

[13] Shi, Y.J., Li, Q.Z., Wang, Y.Q. and Chen, Q. Loading Capacity of Composite Slim Beam in the Sagging Moment Region. Journal of Harbin Institute of Technology, 2004, 36(11): 1550-1553. (In Chinese).

[14] Lu, X.H., M, Makelainen, P. Strength and Stiffness of Composite Slim Floor Beams. Proceedings of the 4st Pacific Structural Steel Conference, Singapore '95, Singapore, 1995: 93-100.

[15] Li, Q.Z. Flexural Stiffness and Bending Capacity of Simply-supported Composite Slim Beam with Deep Deck. Master Thesis, Tsinghua University, Beijing, China, (1995).

[16] L.P. Ye. Concrete structures, Volume I. Tsinghua University Press, Beijing, China, 2002. (In Chinese).
