Interface Shear Force of Steel and GFRP Deck Composite Beam under the Effect of Temperature and Creep

Abstract:

A new type steel and glass fiber reinforced polymer (GFRP) deck composite beam has been proposed. The relative slip and shear force on the interface of steel and GFRP deck composite beam appears to a certainty with the external loading, which induced internal force redistribution between GFRP deck and steel beam and shear connector, especially GFRP is a resin material, its physical and mechanical properties will change with temperature and time. According to the structure and bearing characteristics, the interface shear force differential equations that considering the temperature and creep effects were presented, the theoretical calculating formula of shear force were given under the uniform load. Results of calculation showed that the shear force of composite cross-section would increases with the increase of the connection stiffness, the increase of load, the change of temperature and the time. Loading effect and temperature changes creates a relatively larger impact on the shear force of the composite beam, while the stiffness of the connective interface and the creep effect of the GFRP material to composite beam shear force were much little.

• Periodical: Advanced Materials Research (Volumes 163-167)
• Pages: 2181-2184
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.163-167.2181
• Online since: December 2010
• Authors: De Xuan Wang, Jun Hua Huo, Lian Guang Wang
• Keywords: Composite Beam, Creep Effect, GFRP Deck, Interface Shear Force, Temperature Effect

References

[1] D. C. Keelor, Y. Luo,C. J. Earls. Service Load Effective Compression Flange Width in Fiber Reinforced Polymer Deck Systems Acting Compositely with Steel Stringers. Journal of Composites for Construction, Vol. 8, No. 4, August 1, 2004. PP：289-297.

DOI: 10.1061/(asce)1090-0268(2004)8:4(289)

[2] Thomas Keller, Herbert Gürtler. Composite Action and Adhesive Bond between Fiber-Reinforced Polymer Bridge Decks and Main Girders. Journal of Composites for Construction, Vol. 9, No. 4, August 1, 2005. PP：360-268.

DOI: 10.1061/(asce)1090-0268(2005)9:4(360)

[3] H. A. Salim,M. Barker and J. F. Davalos. Approximate Series Solution for Analysis of FRP Composite Highway Bridges。Journal of Composites for Construction, Vol. 10, No. 4, August 1, 2006. PP：357-366.

DOI: 10.1061/(asce)1090-0268(2006)10:4(357)

[4] Jonathan Moses. Evalution of effective width and distribution factors for GFRP bridge decks supported on steel girders[D], University of Pittsburgh, (2005).

DOI: 10.1061/(asce)1084-0702(2006)11:4(401)

[5] Wang Lian-guang. Structural theory and calculating analysis of steel and concrete composite structure[M], Science Press，2005，In Chinese.

[6] Li Guo-qiang, Han Lin-hai. The structure of steel and steel - concrete composite fire resistant design [M]，China Building Industry Press, 2006，In Chinese.

[7] Kevin Jackson Smith。Compression creep of a pultruded E-glass/polyester composite at elevated service temperatures[D]. Georgia Institute of Technology，August (2005).
