Time-History Analysis of Seismic Response for the Concrete-Filled Steel Tubular Wind Turbine Tower Based on Finite Element Method

Abstract:

In the article based on the geometric characteristics of the tower and force characteristics, the author designs the concrete-filled steel tube (CFST) 3 limbs column tower, and establishes finite element model of the tower. We carry on time history analysis of the concrete-filled steel tubular wind turbine tower based on finite element method when the earthquake wave is different. Under rare earthquake, the majority bars of the concrete-filled steel tube 3 limbs column tower are in the elastic stage, only a small number of bars in the top and the bottom are into the plastic phase. The post-seismic displacement at the top of tower is 1.1m which is slightly less than the tower height of 1 / 50 (1.26m) and meets the seismic requirements of the region. The analytical result may provide the foundational test data and advice for the design of the CFST wind turbine tower.

• Periodical: Advanced Materials Research (Volumes 163-167)
• Pages: 2176-2180
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.163-167.2176
• Online since: December 2010
• Authors: Yang Wen, Fei Zhou
• Keywords: Concrete-Filled Steel Tubular Wind Turbine Tower, Earthquake Wave, Finite Element, Time History Analysis

References

[1] Guoxi Liu, Aiqun Zhao Etc: Wind power utilization technology lecture. Rural energy, 2002，7 (5) ：31-34. In Chinese.

[2] Min Ke: 2001 Summary of high-tech development. Beijing: Chinese Academy of Science and Technology Policy and Management Institute, 2001 In Chinese.

[3] Suxia Wang: Domestic and international situation and development trend of wind power. Public power, 2007，34(5)：3-6. In Chinese.

[4] Shouyuan Ni: Wind Power Seminar, The first wind turbine of the type of stress and structure. Solar Energy, 2000，23(2)：2-4. In Chinese.

[5] Wei Guan, Yan Lu: Overview and domestic wind power development. Jilin Electric Power, 2008，10(2)：1-2. In Chinese.

[6] FEMA 440 NEHRP Improvement of Nonlinear Static Seismic Analysis Procedures Federal Emergency Management Agency Prepared by Applied Technology Council (ATC-55Project), (2005).

[7] Ping Lu, Huifang Qin, Zhiyun Luan: Finite element method based on wind turbine tower structure dynamic analysis. Mechanical Engineering, 2002，24 (9)：2-4. In Chinese.

DOI: 10.3901/jme.2002.09.127

[8] Lu Ping, Huang Shanqiu, Zhang Jun, Song Xiangeng: Cylindrical wind turbine tower structure in static and dynamic finite element analysis. Solar Energy, 1997，16(4)：3-5.
