Theoretical Analysis on Heat Transfer Characteristics of Metal Rubber

Abstract:

Based on the basic components of the porous Metal Rubber (MR) materials, all kinds of heat transfer modes were analyzed. Wire helix was considered as the micro-element of Metal Rubber by analyzing the characteristics of processing components of Metal Rubber. According to the acoustoelectric analogy method, the heat transfer model of MR was established on the basis of arrangement of wire helix and Fourier Law. The formula of thermal conductivity coefficient was derived. And the LFA 427 instrument was used to obtain thermal conductivity characteristics of MR experimentally. The results showed that the model had certain application. This model was valuable for the analysis of the thermal properties and the design of Metal Rubber. It provided theoretical support for the further engineering application of Metal Rubber in the field of heat insulation.

• Periodical: Advanced Materials Research (Volumes 183-185)
• Pages: 1696-1700
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.183-185.1696
• Online since: January 2011
• Authors: Bin Zhu, Jie Hong, Yan Hong Ma
• Keywords: Metal Rubber, Thermal Conductivity (TC), Thermoelectricity Analogy, Wire Helix

References

[1] Zhu H, Sankar B V, Haftka R T, et al. Optimization of Functionally Graded Metallic Foam Insulation under Transient Heat Transfer Conditions. Structural and Multidisciplinary Optimization，2004，28: 349-355. (in Chinese).

DOI: 10.1007/s00158-004-0463-3

[2] Yan Changhai, Meng Songhe, Chen Guiqing. Heat Transfer of Open Metal Foam. Functional Materials, 2006, 37(8): 192-194., (in Chinese).

[3] Ma Yanhong, Wang Hong, Li Haoyu, et al. Study on Metal Rubber Material's Characteristics of Damping and Sound Absorption. Proceedings of ASME TURBO EXPO 2008, Berlin, Germany, GT2008-50961.

[4] Liu Wei, Fan Aiwu, Huang Xiaoming. Theory and Applications of Heat and Mass Transfer in Porous Media, Science Press, 2006(in Chinese).

[5] Chen Yanqiu, Guo Baoting, Zhu Zigen. Investigation on the Stiffness Characteristics and Stress-Strain Relation of Metal Rubber[J]. Journal of Aerospace Power, 2002, 17 (4): 416-420 (in Chinese).

[6] Zhang Yongcun, Heat Transfer Performance Analysis of Cellular Materials and Optimization Design of Heat Dissipation Structure[D], Dalian University of technology 2008 (in Chinese).
