Simulation on Pipe Joints Expansion Technology of NiTiNb Shape Memory Alloy

Abstract:

In order to study the low-temperature expansion process of NiTiNb shape memory alloy, this paper makes use of numerical simulation method to complete the simulations and analysis. The shape memory effect of NiTiNb alloy pipe joints under different expansion temperatures and expansion strains have been compared and evaluated. Through simulations of low-temperature expansion and elevated temperature shape recovery of NiTiNb alloy pipe joints, the relationships between elastic deformation, phase transformation deformation and recovery ratio under different expansion temperatures and expansion strains have been acquired. The results show that the highest expansion strain should below 11%, in consideration of recovery ratio and recovery temperature, the optimal expansion temperature range is -60~-50°C .

• Periodical: Advanced Materials Research (Volumes 189-193)
• Pages: 1711-1717
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.189-193.1711
• Online since: February 2011
• Authors: Gen Lin Yang, Zhi Ming Ni, Jin Han, Er Min Wang
• Keywords: Expansion Strain, Expansion Temperature, NiTiNb Alloy, Numerical Simulation, Pipe Joint

References

[1] T. Saburi, in: K. Otsuka, C.M. Wayman (Eds. ), Shape Memory Materials, Cambridge University Press, Cambridge, UK, 1998, p.49–73.

[2] K. Otsuka, X.B. Ren: Intermetallics Vol. 7 (1999), p.511~528.

[3] J. Van Humbeeck: Mat. Sci. Eng. A273-275 (1999), pp.134-148.

[4] T. Duerig, A. Pelton, D. Stöckel: Mat. Sci. Eng. A273-275 (1999), pp.149-160.

[5] Liancheng Zhao, Wei Cai and Yufeng Zheng: Shape Memory Effect and Superelasticity in Alloys(National Defence Industry Press, Beijing, China 2002).

[6] Mingze Ji: A Dissertation Submitted for the Degree of Master, BeiHang University, BeiJing, China (2004: 2~3).

[7] Huaqiang Mo: A Dissertation Submitted for the Degree of Doctor of Philosophy, SiChuan University, ChengDu, China (2003: 2~4).

[8] Xiangqian Yin, Baodong Gao and Xujun Mi: Chinese Journal of Rare Metals Vol. 32 No. 5 (2008), China, p.579~583.

[9] Dong Han, Fushun Liu and Yan Li: Acta Aeronautica Et Astronautica Sinica Vol. 27 No. 4 (2006), China, p.703~707.

[10] Lixuan Zheng: A Dissertation Submitted for the Degree of Master, SiChuan University, ChengDu, China (2005: 41).

[11] Liancheng Zhao and Wei Cai: Acta Metallurgica Sinica Vol. 33 No. 1 (1997), China, p.90~98.

[12] XiangMing He, Lijian Rong and Desheng Yan: Acta Metallurgica Sinica Vol. 40 No. 7 (2004), China, p.721~725.

[13] Lei Wang, Desheng Yan and Zhimin Jiang: Journal of Materials Engineering No. 7 (2004), China, p.60~63.
