Temperature Field Modeling and Thermal Deformation Analysis of Turning and Milling Machining Center

Abstract:

Taking the high-speed CX series vertical milling compound machining center of CX8075 produced by Anyang Xinsheng Machine Tool Co., Ltd. as example, the machine three-dimensional simplified model is established, the source of the heat and the distribution of the important hot-points are analyzed, the machine temperature field distribution is derived which lays a foundation for the thermal error compensation. Taking into account the moving part-saddle of the machining center, its mathematic model is obtained, the important hot-points are studied, the thermodynamic parameters are determined. Based on ANSYS finite element method, the steady-state temperature field and the thermal deformation of saddle are presented, the optimal design of high-speed and high-accuracy machine tool is doned and its thermal deformation analysis is realized.
