Resistance Microwelding of Au/Ni-Plated Phosphor Bronze Sheet to Insulated Cu Wire

Abstract:

Resistance microwelding of Au/Ni-plated phosphor bronze sheet to insulated Cu wire have been investigated using mechanical testing, optical microscopy, scanning electron microscopy, and energy-dispersive X-ray spectroscopy. The results show that mechanisms of joint formation involve solid-state bonding with Au and Cu atoms diffusion at low welding current, a combination of brazing and solid-state bonding at high welding current. Due to the hindrance of Ni plating which has a higher melting temperature and hardness, the joint breaking force is smaller than that without plating.

• Periodical: Advanced Materials Research (Volumes 189-193)
• Pages: 3596-3600
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.189-193.3596
• Online since: February 2011
• Authors: Bing Hua Mo, Zhong Ning Guo, Yuan Bo Li, Guan Wang
• Keywords: Au/Ni Plating, Brazing, Insulated Cu Wire, Resistance Microwelding, Solid-State Bonding

References

[1] Y. Zhou: Microjoining and Nanojoining (Woodhead Publishing Limited, Cambridge, England 2008).

[2] S. Fukumoto, T. Matsuo, H. Tsubakino and A. Yamamoto: Mater. Trans. Vol. 48 (2007), p.813.

[3] Z. Chen, Y. Zhou: J. Mater. Sci. Vol. 42 (2007), p.5756.

[4] S.T. Riches: TWI Journal Vol. 3 (1994), p.155.

[5] W. Tan, Y. Zhou and H.W. Kerr: Metall. Mater. Trans. A Vol. 33 (2002), p.2667.

[6] S. Fukumoto and Y. Zhou: Metall. Mater. Trans. A Vol. 35 (2004), p.3165.

[7] S. Fukumoto, Z. Chen and Y Zhou: Metall. Mater. Trans. A Vol. 36 (2005), p.2717.

[8] B.H. Mo, Z.N. Guo, Y.B. Li and C. Liu: Key Eng. Mater. Vols. 447-448 (2010) p.461.

[9] T.B. Massalski: Binary Alloy Phase Diagrams (ASM International, Materials Park, OH 1990).
