Defects Analysis and Improvement for Electricmotorcar Aluminum Alloy Wheel by Gravity Casting

Abstract:

Analysis the electricmotorcar aluminum wheels’ hole defect on macroscopic and microscopic, observed that the main defects、concentrated site and the main alloy phase. Combined with the local casting technological parameters, the filling and solidification process of aluminium alloy hub was simulated by using Anycasting software. The results showed that: castings filling smoothly, at the junction of the spoke and the rim and the hub central are easy to produce casting defects. Using the optimized process parameters that is lower pouring temperature, higher pouring height and set the vent to experiment, after comparing the results with the original process known, Shrinkage and porosity defects decreased, but there are still some degree of defects, indicating optimized process parameters have some effect.

• Periodical: Advanced Materials Research (Volumes 189-193)
• Pages: 3880-3885
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.189-193.3880
• Online since: February 2011
• Authors: Fei Fei Wang, Yan Wei Sui, Yao Jian Ren, Xin Zhao, Zhi Sun
• Keywords: Aluminium Alloy, Defect, Electricmotorcar Wheel, Gravity Casting, Numerical Simulation

References

[1] An-ying Ye, Ying Ma, Zheng-ming Chen. CAE analysis and modify to the air leakage defects of the net aluminum wheels by gravity casting. Casting, 2008: 176-180. In Chinese.

[2] Da-wei Su, Yu-tao Zhao. Simulation analysis to the filling and solidification process of the aluminum wheel. Special casting and colour alloy, 2007: 682-684. In Chinese.

[3] Da-wei Su. Numerical simulation and technology optimization of the aluminum alloy wheels of automobiles by low pressure casting. [master degree theses]. JiangSu university: 2008. In Chinese.

[4] Dao-an Kang, Yi Yang, Ming Wu. The research current situation and development of the filling and solidification numerical simulation of the aluminum casting. Metal casting welding technology, 2008: 109-113. In Chinese.

[5] Low times organization testing method of deformation aluminum and aluminum products. GB/T3246. 2—2000: 19-31.

[6] Mattia Merlin, Giulio Timelli , Franco Bonollo , Gian Luca Garagnani. Impact behaviour of A356 alloy for low-pressure die casting automotive wheels. Department of Engineering, University of Ferrara, Via Saragat 1, I-44100 Ferrara, Italy. Department of Management and Engineering, University of Padova, Stradella S. Nicola 3, I-36100 Vicenza, Italy : 1060-1073.

DOI: 10.24867/ijiem-2018-4-229

[7] You-fu Yi, Si-yuan Long, Shao-yong Xu. The microstructure and mechanical properties of the A356 aluminum alloy wheel by low pressure casting. Special casting and colour alloy, 2008: 373-375. In Chinese.

[8] Metallographic Analysis》group of Shanghai jiaotong university. Metallographic Analysis. National defense industry press, 1982. In Chinese.
