Study on the Radial Vibration of an Annular Plate Ultrasonic Concentrator with Edge Section

Abstract:

The radial vibration of an annular ultrasonic concentrator with edge section is studied. Based on the electromechanical analogy, the radial equivalent circuit and the frequency equation of the concentrator are derived, the radial displacement amplitude magnification and the nodal circle equation are given. The relationship between the radial displacement amplitude magnification and radius ratio of the annular vibrator at the first and second order vibration mode is obtained. The relationship between the first and the second order radial resonance frequencies and the radius ratio of the annular edge section concentrator is analyzed. The displacement amplitude magnification of the annular vibrator at the second order resonance is lager than that of the first order vibration mode. Especially, when the radius ratio tends to one, the second order resonance frequency of the annular vibrator tends toward infinity. It can be concluded that there is no higher order vibration mode for a thin-walled circular ring. Furthermore, the experimental results show that the theoretical resonance frequencies and the amplitude magnification are in good agreement with the measured results.

• Periodical: Advanced Materials Research (Volume 215)
• Pages: 95-102
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.215.95
• Online since: March 2011
• Authors: H. Xu, S.Q. Liu
• Keywords: Amplitude Magnification, Annular Concentrator, Displacement Nodal Circle, Equivalent Circuit, Frequency Equation

References

[1] Shamoto E, Moriwaki T. Ultrasonic precision diamond cutting of hardened steel by applying ultrasonic elliptical vibration cutting[J]. Annuals of CIPR, 48(1)：441-444, (1999).

DOI: 10.1016/s0007-8506(07)63222-3

[2] Zhou Guangping, LI Mingxuan. A study on ultrasonic solid horns for flexural mode[J]. Journal of Acoustical Society of American, 107(3)：1358-1362, (2000).

DOI: 10.1121/1.428423

[3] Tao Xie, Haiqun Qi. Experiment research on the ultrasonic vibration [J]. Chinese mechanical engineering, 17(3): 224-226, (2006).

[4] Shuyu Lin. The radial composite piezoelectric ceramic transducer[J], Sensors and Actuators, 141: 136-143. (2006).

DOI: 10.1016/j.sna.2007.07.005

[5] Jae-Hoon Kang. Three-dimensional vibration analysis of thick, circular and annular plates with nonlinear thickness variation[J]. Computers and Structures 81(2003), 1663-675.

DOI: 10.1016/s0045-7949(03)00168-8

[6] Gladitll, G. M. L., The vibration of Mechanical resonators (II)[J]: Rings, Discs, and Rods of Arbitrary Profile. J. Sound and Vibration., 1967, 6(3): 351-64.

DOI: 10.1016/0022-460x(67)90208-8

[7] Kleesattel, C., Uniform Stress Contours for Disk and Ring Resonators Vibrating in Axially Symmetric Radial and Torsional Modes[J]. Acustica, 20: 1-3, (2004).

[8] Yujiong Gu, Zhaoying Zhou, application and designing method of the four-pole network based on the ultrasonic vibration system., mechanical engineering, 3(3) 94-101, (1997).
