The Top-Stem-Cutter for the Top-Cutter Machine Design and Fem Analysis

Abstract:

Designing a top-stem-cutter part for the top-cutter machine. Adams was used to analysis the moving simulation, with the help of it, the normal structure and dimension were inspected and verified. In this paper, the tract of the top-stem-cutter part analyzed by Adams was matched the result from the theoretical calculations; the model and structure also had been analyzed by Ansys, which provided a way to analysis and verify the machine, and analysis of the model can get the nature frequency of the top-stem-cutter part, and it had given us a way to lower frequency of machine; the structure analysis provided that the stress of the top-stem-cutter part should be lower than certain value.

• Periodical: Advanced Materials Research (Volume 216)
• Pages: 809-813
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.216.809
• Online since: March 2011
• Authors: Chun Yao Wang, Fa Chen, Min Lei, Yong Xin Jiang, Yue Liu
• Keywords: Cotton Top-Cutter Machine, Model Analysis, Moving Simulation, Structure Analysis, Top-Stem-Cutter Part
