Applying Modular Greening Technology in Living Walls of Shanghai Expo

Abstract:

The living wall of theme pavilion of Shanghai Expo was enrolled in World Record Association for its 5,000 m² area. The wall with modular design concept was also a symbol of energy-saving. This study took Shanghai Expo as a case to explore the modular greening technology including theory analysis, design factor and cooling effect. The technology has the following virtues: Environment-friendly idea of recycled waster paper pulp, reused litter and other organic waste; economy concept of collecting rain, holding water and nutrient in medium and tolerating extensive management; integrity medium formula; modular suitable to plant upward growth; applicable for district of hot summer and cold winter, Plum rain and typhoons. After victory exhibition of the World Expo, living wall will further popularize in compact metropolitans.

• Periodical: Advanced Materials Research (Volume 224)
• Pages: 125-131
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.224.125
• Online since: April 2011
• Authors: Hong Bing Wang, Jun Qin, Yong Hong Hu, Li Dong
• Keywords: Cooling Effect, Culture Medium, Green Building, Plant-Covered Wall, Vertical Greening

References

[1] NH Wong, AYK Tan, PY Tan, K Chiang and NC Wong: Acoustics Evaluation of Vertical Greenery Systems for Building Walls. Building and Environment 45 (2010), p.411–420.

DOI: 10.1016/j.buildenv.2009.06.017

[2] WJ Stec, AHC Paassen and A Maziar: Modelling the Double Skin Facade with Plants. Energy and Buildings 37 (2005), p.419–27.

DOI: 10.1016/j.enbuild.2004.08.008

[3] KJ Kontoleon, EA Eumorfopoulou: The Effect of the Orientation and Proportion of a Plant-covered Wall Layer on the Thermal Performance of a Building Zone. Building and Environment 45 (2010), p.1287–1303.

DOI: 10.1016/j.buildenv.2009.11.013

[4] K Shibuya, Y Soh and S Satoh: Block Survey of Wall Covered with Plant in the City of Tokyo and Evaluation of Thermal Environment of Wall Greening System. Bulletin of Tokyo Metropolitan Agriculture and Forestry Research Centre 2 (2007), p.119–127. (in Japanese)

[5] EA Eumorfopoulou, KJ Kontoleon: Experimental Approach to the Contribution of Plant-covered Walls to the Thermal Behavior of Building Envelopes. Building and Environment (5) 44 (2009), p.1024–1038.

DOI: 10.1016/j.buildenv.2008.07.004

[6] P Krushe, M Krushe, D Althaus and I Gabriel: Okologisches Bauen Herausgegeben vom Umweltbundesamt (Wiesbaden und Berlin: Bauverlag 1982).

[7] Information on http://www.greenroofs.net/.

[8] M Köhler: Green Facades—a View Back and Some Visions. Urban Ecosystems (4) 11 (2008), p.423–436.

DOI: 10.1007/s11252-008-0063-x

[9] YH Hu, J Qin et al.: The Research of Plant Community Reducing Heat Island in Urban Habitats (China Building Industry Press 2010). (in Chinese)

[10] Information on http://www.shijiejilu.org.cn/_d270057044.htm

[11] SZ Tong: Modular Theory, Design Method and Application (Chinese Standard Press 2000). (in Chinese)

[12] M Zhang, J Qin, QH Liu and YH Hu: Study on Growing Media for Living Wall. Acta Agriculturae Jiangxi (1) 21 (2009), p.35–39. (in Chinese)
