Lateral Vibration Research for Railway Deck Steel Plate Bridges

Abstract:

In this paper, the vehicle-bridge lateral vibration mechanism was analyzed; the vehicle-bridge vibration model was built and the lateral reinforcement schemes of open steel plate bridges were designed. Numbers of analysis were carried out for the lateral vibration of 40m deck steel plate bridges before and after reinforcement, under input of random artificial hunting waves and track irregularity. The results showed that, the frequency of hunting motion is approaching loaded frequency of the girder. The larger lateral amplitude appears on the bridge when the hunting wavelength is around 8~9m and the velocity of the train is around 55~70km/h. The wavelength is longer, the resonant velocity of the bridge is higher.

• Periodical: Advanced Materials Research (Volumes 243-249)
• Pages: 1646-1650
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.243-249.1646
• Online since: May 2011
• Authors: Wen Ping Li, Shu Li Chen, Mu Biao Su
• Keywords: Deck Steel Plate Bridges, Lateral Vibration, Resonant Vibration, Vehicle-Bridge System

References

[1] China Acadamy of Railway Sciences: Test report on Daling River Bridge in speed Incresed for Freight Trains, (China Acadamy of Railway Sciences, Beijing1996) , in Chinese.

[2] Bridge Inspection Team of Zhengzhou Railway Burea: Test Report on Vibration of Zhengzhou Yellow River Bridge, Beijing-Guangzhou Railway, (Bridge Inspection Team of Zhengzhou Railway Bureau,Zhengzhou 2000), in Chinese.

DOI: 10.1002/stab.201201522

[3] Rong Deng, Yan Gao and Jiahua Shen: Research of lateral vibration for deck plate steel bridges, Chinese Railways, Vol 10 (2003). pp.23-25, in Chinese.

[4] Futian Wang: Vehicle dynamics. (China Railway Publishing House, Beijing 1983), in Chinese.

[5] Jianzhong Li, Lichu Fan: Lateral Vibration Research of the Deck Steel Plate Bridges under Raised Speed Freight Train,Journal of Tongji University,Vol. 1(2001). pp.104-108, in Chinese.

[6] Ray Clough, Joseph Penzien: Structural Dynamics, (Computers and Structures Inc.1995).

[7] Xueqin Cao: Lateral Vibration of the Steel Truss Bridges, (China Railway Publishing House, Beijing1991), in Chinese.

[8] He Xia, Nan Zhang, Dynamic interaction of vehicles and structures, (Science Press,Beijing 2002), in Chinese.

[9] Xinmin Wang: ANSYS Numerical Anasysis of Engineering Structures, (China Communication Press. Beijing2007), in Chinese.
