Local Stress Analysis of Orthotropic Steel Bridge Decks in High-Speed Railway

Abstract:

Orthotropic decks are commonly used in high-speed railway bridges. Finite-element model is established by ANSYS for orthotropic steel bridge deck in this paper. Taking the standard PDL ZK live load as the train load, the local stress of the rib-to-deck joint, the rib-to-crossbeam joint, and the cut-outs of the crossbeam are analyzed respectively. Analysis results show that the stress concentration of bridge deck mainly appears at the intersecting part of the U-shaped rib, crossbeam, and bridge deck. In the whole bridge deck, the local stress level of the cut-outs in crossbeam is almost the highest, and the cut-outs is distorted seriously; the maximum stress of crossbeam cut-outs is mainly concentrated at the lower arc of the cut-outs, which is one of the positions prone to fatigue failure.

• Periodical: Advanced Materials Research (Volumes 243-249)
• Pages: 1659-1663
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.243-249.1659
• Online since: May 2011
• Authors: Yun Sheng Li, Yang Tian, Yan Ling Zhang
• Keywords: Fatigue, Local Stress, Orthotropic Steel Bridge Deck, Stress Concentration

References

[1] Xiaoyan Tao. Research on key structure details of long-span steel bridges. China Academy of Railway Sciences, (2008) (in Chinese)

[2] Chunhua Zeng, Shinjian Zou. Fatigue analysis method and application. edtied by National Defense Industry publishing house (1991) (in Chinese)

[3] Dongsheng Qian. On Fatigue of Steel Orthotropic Deck Structure Comments on Researches for Strengthening the Severn Crossing in UK. Bridge Construction 2(1996), pp.8-13. (in Chinese)

[4] M. H. Kolstein. Fatigue classification of welded joints in orthotropic steel bridge decks. Netherlands, Delft University of Technology (2007)

[5] Fundamental code for design on railway bridge and culvert. edtied by China railway publishing house (2005) (in Chinese)

[6] Interim Provisions for design on Beijing-shanghai high-speed railway. edtied by China railway publishing house (2005) (in Chinese)

[7] Paula Tsakopoulos, Johnw.Fisher. Fatigue performance and design refinements of steel orthotropic deck decks based on Full-scale Laboratory Tests. Steel Structures 5 (2005), pp.211-223.

DOI: 10.1080/15732480412331294704

[8] Ali Touran, Alex Okereke. Performance of orthotropic bridge decks. Journal of performance of constructed facilities 2 (1991), pp.56-71.

DOI: 10.1061/(asce)0887-3828(1991)5:2(134)

[9] J.Janss. Fatigue of welds in orthotropic bridge deck pannels with trapezoidal stiffeners. Construct Steel Research 9 (1988), pp.147-154.

DOI: 10.1016/0143-974x(88)90005-3
