Experimental Research on Setting Stiffening Rib of Corner Joints in Gabled Frames

Abstract:

In order to clear constructional design of corner joint, it is necessary to further investigate mechanical property of corner joint in gabled frames. Through static test of comparing the panel zone with and without inclined stiffener. Some conclusions are given in the article. The load displacement curves show that the capacity of oblique nodes installed within stiffening rib components is enhanced i.e.40% more than those without stiffening rib nodes. The results reveal that in the gabled frames, the corner node with the inclined stiffening rib can improve the bearing capacity of the specimens. When the extraterritorial flange is tension, the erection of the inclined stiffening rib can prevent structural failure and improve effectually the ductility of the structure.

• Periodical: Advanced Materials Research (Volumes 243-249)
• Pages: 343-346
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.243-249.343
• Online since: May 2011
• Authors: Yu Wang, Yong Jun Liu, Hao Bang Li
• Keywords: Corner Joint, Full-Scale Experiment, Gabled Frame, Stiffening Rib

References

[1] Mingzhong Wei: Steel Structure . Wuhan Industry University Publishers, 2000.

[2] P.J. Trebilcock: Building Design Using Cold Formed Steel Sections: An Architect's Guide. UK: The Steel Construction Institute , 1994.

[3] China Association for Engineering Construction Standardization. Technical Specification for Steed Structure of Light-weight Buildings with Gabled Frames. Beijing: China Planning Press, 2003.

[4] Alexander Metal: Metal Building Systems. McGraw-Hill Inc, 1997.

[5] Yongjiu Shi, Xinjun Liao, Yuanqing Wang. Journal of China University of Mining and Technology, 2005(3): 327~330.

[6] Yu Wang, Yongjun Liu: Building Science, 2009(7): 21-23.
