An Approach to Determine the Stiffness Reduction Factor of Tunnel Lining

Abstract:

Based on the segmental joint tests, it was found that the practical range of joint flexural rigidity was in range of 8500-29000kN•m/rad. A simplified method for determining the stiffness reduction factor of tunnel lining() was proposed using results from the segmental joint tests in which some parameters were obtained by calibration against a 3D Numerical analysis. The influence of joint flexural rigidity, soil resistance coefficient, thickness of tunnel lining and tunnel calculation radius on the stiffness reduction factor of tunnel lining was examined. The stiffness reduction factor can be simply expressed as a function of joint flexural rigidity ratio, soil resistance coefficient, thickness of tunnel lining and tunnel calculation radius for the typical tunnel lining.

• Periodical: Advanced Materials Research (Volumes 243-249)
• Pages: 3659-3662
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.243-249.3659
• Online since: May 2011
• Authors: Hai Ying Zhou, Li Xin Li, Ting Guo Chen
• Keywords: Flexural Rigidity, Jointed Segmental Lining, Shield Tunnel, Stiffness Reduction Factor

References

[1] Liu, J.F., and Liu, B., and Tao, L,G. Journal of Shenyang Jianzhu University(Natural Science), Vol. 25 (2009), p.28 (in Chinese)

[2] Tanan Chub-uppakarn. Tunnelling and underground space technology, Vol. 25 (2010), p.490

DOI: 10.1016/j.tust.2010.02.003

[3] Muir Wood, A.M. Getotechnique, Vol. 25 (1975), p.115

[4] Liu, J.H., and Hou, X.Y, in: Shield-driven tunnels, edited by China Railway Press, Beijing (1991), in press.(in Chinese)

[5] Lee, K. M., Hou, X. Y., Ge, X. W., and Tang, Y. International Journal of Analytical and Numerical Methods in Geomechanics. Vol. 25 (2001), p.115

[6] A. M. Hefny, F.C Tan and N. F. Macalevey. Journal of the institution of engineers. Vol. 44 (2004), p.108
