Numerical Analysis and Optimization of Wedge Box of Diagonal Brace

Abstract:

Force transmission triangular box as the bracing’s bracket is widely applied in the deep foundation, but its performance was not studied in depth. In order to evaluate the working performance of force transmission triangular box as bracing’s bracket, the paper use the finite element software ANSYS to simulate and analyze its mechanical behavior. The bearing capacity, deformation and stress distribution of the components were discussed and compared with the result from elastic bending theory of small deflections of its end-plate deflection. The dangerous sections of member and the inner force distribution in the general work load status were obtained. And the stress concentration was improved. the results can provide reference for the design and construction.

• Periodical: Advanced Materials Research (Volumes 243-249)
• Pages: 3652-3658
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.243-249.3652
• Online since: May 2011
• Authors: Wei Li
• Keywords: Bearing Capacity, Composite Structure, Distortion, Finite Element Analysis (FEA), Force Transmission Triangular Box

References

[1] Xinmin Wang, in: ANSYS-engineering structure numerical analysis, in Chinese, edited by China Communications Press, Beijing2007.

[2] Zhenhai Guo, Xudong Shi, in: Reinforced concrete theory and analysis , in Chinese, edited by TSINGHUA University Press,Beijing2003.

[3] Boyuan Yang, Yitong Zhang, in: Construction Elasticity and Plasticity , edited by China Machine Press,Beijing2003,in China.

[4] Lihong Wang, Journal of Dalian Fisheries University Vol.74-78(1981).
