A Loading Test Method of Prototype Structure for Nanjing Changjiang Tunnel

Abstract:

Considering the features of underwater shield tunnel with large cross-section, a prototype test of segmental lining structure for Nanjing Changjiang Tunnel (Φ14.5m) is carried out by using a new loading test method. And with “Multi-function Shield Tunnel Structure Test System” developed according to this test method, the effect of high hydraulic pressure can be equivalently imposed upon the structure by hoop, and then the earth pressure can be equivalently applied to the structure by radial concentrated force. The structures were loaded by the device according to a certain hydraulic and earth pressure. Meanwhile, the mechanical characteristics can be further studied. In a word, it can provide reliable test means for research, design and construction of underwater shield tunnel project.

• Periodical: Advanced Materials Research (Volumes 250-253)
• Pages: 2605-2611
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.250-253.2605
• Online since: May 2011
• Authors: Kun Feng, Chuan He, Ji Min Zhou, Zong Xian Su
• Keywords: High Hydrostatic Water Pressure, Loading Method, Prototype Test, Segmental Lining Structure, Underwater Shield Tunnel

References

[1] HE Chuan, ZHANG Jiangang, YANG Zheng. Model test study on the mechanical characteristics of segment lining for the Wuhan Yangtze River tunnel. China Civil Engineering Journal, Vol.41 (2008), p: 85~90. (in Chinese)

[2] HE Chuan, FENG Kun, YANG Xiong. Model test of large profile segmental lining for Nanjing Changjiang Tunnel. Chinese Journal of rock mechanics and engineering, Vol.26 (2007), p:2260~2269. (in Chinese)

[3] Takimoto Takaya, Hayashi Mitsutoshi, Saitoh Masayuki. Loading test of shield tunnel lining (No.1), Procedings of Annual Conference of the Japan Society of Civil Enginneers, Vol.49 (1994), p: 1330~1331. (in Japanese)

[4] Hiroshi Nakamura, Toshikazu Kubota, Mamoru Furukawa, et al. Unified construction of running track tunnel and crossover tunnel for subway by rectangular shape double track cross-section shield machine. Tunneling and Underground Space Technology, Vol.18 (2003), p: 253~262.

DOI: 10.1016/s0886-7798(03)00034-8

[5] WANG Rulu, SONG Bo, WANG Qi. Lining experiment and structure analysis of bi-circular shield tunnel with staggered joint splice on segments. Underground Engineering and Tunnels, No.1 (2001), p: 12~15. (in Chinese)

[6] GUO Zhijie, LU Liang, LIU Zuhua. Loading method of test for double-circular face shield tunnel lining. Structural Engineers, No.3 (2004), p: 64~71. (in Chinese)

[7] WANG Biao, LIU Zuhua, LU Liang. A loading method of the test for lining whole wreath of Shanghai Chongming Tunnel. Construction Technology, Vol.35 (2006), p: 52~54. (in Chinese)
