Nonlinear FEM and Control Method for Super-Long Span Three Main Trusses and Three Cable Planes Railway Cable-Stayed Bridge

Abstract:

The Anqing Changjiang River Railway Bridge is an important fixed link across the Changjiang River in Anqing both the Nanjing-Anqing Intercity Railway and Fuyang-Jingdezhen Railway. Its main bridge is a six-span continuous steel truss girder cable-stayed bridge with main span of 580 m. The purpose of this paper is to describe some of its main features and FE model for geometrical nonlinearity using the finite element program ANSYS as well as control method of stress-free status for erection of cable-stayed bridge. Based on geometrical nonlinear analysis theories, secondary development of ANSYS using APDL was accomplished.

• Periodical: Advanced Materials Research (Volumes 255-260)
• Pages: 1065-1069
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.255-260.1065
• Online since: May 2011
• Authors: Zhi Shuo Yang, Mei Xin Ye, Yan Qun Zhou, Li Ou
• Keywords: Cable Stayed Bridge with Three Cable Planes, Construction Control, Finite Element Model (FEM), Geometrically Nonlinear, Long-Span, Secondary Development of ANSYS Using APDL, Structural Analysis

References

[1] M. Virlogeux: Engineering Structures . Vol. 21(1999), p.737–755.

[2] Haizhu Xiao, Wei Xu, Zongyu Gao: Bridge Construction. Vol. 5(2009), p.6–8 (in Chinese).

[3] P. -H. Wang : Computers and StructuresVol. 80 (2002), p.165–182.

[4] Ernst HJ: Der Bauingenieur. Vol. 40(1965), p.52–5.

[5] Fleming JF: Int J ComputStruct. Vol. 10(1979), p.621–35.

[6] Gimsing NJ: JohnWiley and Sons Inc(1997).

[7] PhWang, CgYang: Int J ComputStruct. 60(1996), p.243–60.

[8] Shunquan Qin: Bridge Construction. Vol. 2(2003), p.31–36 (in Chinese).

[9] Xiaohang Huang, Zongyu Gao: Bridge Construction. Vol. 1(2010), p.71–75 (in Chinese).
