J-Automatic Welding Robot Software Design

Abstract:

In this paper, according to nuclear reactor pressure vessel for the J-groove type, independent research and development of a special groove in the J-automatic control system program. This paper introduces a PC-based industrial computer as the host operating system and the functional modules are described respectively, by comparison of a variety of robot programming languages, ultimately to achieve the goal of the program using the Visual C++ MFC platform. The system has a friendly interface, which can be easily set to display, on-line adjustment and automatic welding for the preservation, through simulation experiment with industrial PC connection to verify that the entire system software design is reasonable, functional and meet the actual needs of production.

You might also be interested in these eBooks

Materials Processing Technology, AEMT2011

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 291-294)

Pages:

2949-2953

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.291-294.2949

Citation:

Cite this paper

Online since:

July 2011

Authors:

Hai Feng Song, Xiao Qing Lv, Sheng Sun Hu

Keywords:

Control System, J Type Groove, Software Design
