Numerical Simulation of Temperature Field of Direct Laser Metal Deposition Shaping Process of Titanium Alloys

Abstract:

In order to control the thermal stress of forming process, based on “element birth and death” technology of finite element method, a numerical simulation of three-dimensional temperature field and stress field during multi-track & multi-layer laser metal deposition shaping(LMDS) process is developed with ANSYS parametric design language (APDL). The dynamic variances of temperature field and stress field of forming process are calculated with the energy compensation of interaction between molten pool-powder and laser-powder. The temperature field, temperature gradient, thermal stress field and distribution of residual stress are obtained. The results indicate that although the nodes on different layers are activated at different time, their temperature variations are similar. The temperature gradients of samples are larger near the molten pool area and mainly along z-direction. Finally, it’s verified that the analysis results are consistent with actual situation by the experiments with same process parameters.

• Periodical: Advanced Materials Research (Volumes 295-297)
• Pages: 2112-2119
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.295-297.2112
• Online since: July 2011
• Authors: Yuan Kong, Wei Jun Liu, Yue Chao Wang
• Keywords: Laser Meter Deposition Shaping, Numerical Simulation, Temperature Gradient, Transient Temperature Field

References

[1] PHAM D T.GAULTRS in: A comparison of rapid prototyping technologies(1998)

[2] Y. Huang, G. Liang, and J. Su in: Journal of University of Science and Technology Beijing: Mineral Metallurgy Materials(2004)(in Chinese).

[3] W. D. Bennon and F. P. Incropera, Int. J. in: Heat Mass Transfer 30, 2161(1987).

[4] S. Osher and J. A. Sethian, J. Comput. in: Phys. 79, 12 (1988).

[5] SCHLIENGER E.DIMOS D.GRIFFITH M.MICHAEL J,OLIVER M,ROMERO T,SMU-GERESKY J in: Near net shape production of metal components using LENS (1998)

[6] ATWOOD C L.GRIFFITH M L.HARWELL L D.GREENE D L,RECKAWAY D E,ENSZ M T,KEICHER D M,SCHLIENGER MD,ROMERO J A,OLIVER M S,JEANTETTE F P in: Laser spray fabrication for net-shape rapid product realization LDRD[SAND 99-0739] (1999)

DOI: 10.2172/5657

[7] GRIFFITH M L.SCHLIENGER M E.HARWELL L D in: Understanding thermal behavior in the LENS process (1999)

[8] Ri-qing Ye.SMUGERESKY J E. Bao-long. Zheng Yi-zhang Zhou,LAVERNIA E J in: Numerical modelling of the thermal behavior during the LENS (2006) (in Chinese).

[9] Kai Zhang. Wei-Jun Liu. Xiao-feng Shang in: Research on the processing experiments of laser metal deposition shaping (2007) (in Chinese).

[10] Yan-min Li. Hai-Ou. Yang Xin Lin. Wei-dong Hang. Jian-Guo Li. Yao-He Zhou in: The influences of processing parameters on forming characterizations during laser rapid forming (2003) (in Chinese).

DOI: 10.1016/s0921-5093(03)00435-0

[11] MAZUMDER J.in:Overview of melt dynamics in laser processing [J]. Optical engineering ( 1991)

[12] Ri-Sheng Long. Wei-Jun Liu. Xiao-Feng Shang. in: Numerical simulation of temperature field on lasermetal deposition shaping [J].LASER TECHNOLOGY,(2007) (in Chinese).

[13] KOBRYN P A.MOORE E H.SEMIATIN S L in: The effect of laser power and traverse speed on microstructure,porosity,and build height in laser deposited Ti-6Al-4V( 2000)

DOI: 10.1016/s1359-6462(00)00408-5

[14] Hua.Zhang Ji-luan Pan. Bao-jian Liao in: Study on real-time measurement for temperature field by images colorimetric method[J]-Chinese Journal of Mechanical Engineering (1998) (in Chinese)

[15] Fei Xing. Wei-Jun Liu. et al. On-line,small-eyeshot,large-measurement-range,and high performance thermographic system [J] Chinese Journal of Scientific Instrument (2006) (in Chinese)

[16] LABUDOVIC M, HU D, KOVACEVIC R. in: A three dimensional model for direct laser metal powder deposition and rapid prototyping [J]. Journal of materials science.(2003)

[17] IBARRA-MEDINA J, PINKERTON A. in: A CFD model of the laser, coaxial powder stream and substrate interaction in laser cladding [J]. Physics Procedia, (2010)

DOI: 10.1016/j.phpro.2010.08.060

[18] QI H, MAZUMDER J, KI H. in: Numerical simulation of heat transfer and fluid flow in coaxial laser cladding process for direct metal deposition [J]. Journal of Applied Physics.( 2006).

DOI: 10.1063/1.2209807

[19] TOYSERKANI E, KHAJEPOUR A, CORBIN S. in: 3-D finite element modeling of laser cladding by powder injection: effects of laser pulse shaping on the process [J]. Optics and Lasers in Engineering, (2004)

DOI: 10.1016/s0143-8166(03)00063-0

[20] Risheng, Long Weijun Liu, Fei Xing, Huabing Wang. in: Numerical simulation of thermal behaviour during laser metal deposition shaping. Transactions of Nonferrous Metals Society of China,( 2008) (in Chine)

DOI: 10.1016/s1003-6326(08)60120-x
