The Analysis on Causes of Rupture for a Sucker Rod Made of 20CrMo Alloy

Abstract:

Multiple types of analysis and examinations are applied to analyze the causes of rupture for a sucker rod made of 20CrMo alloy. Based on the results from macro- and micro-fracture analysis, chemical composition analysis, mechanics test and metallographic examination, the generation of cracks can be attributed to the irregularity and impurity in the coating of sucker rod; the stress fatigue from pulling and pressing and the stress corrosion. There is severe banded segregation, non-metal impurity and un-dissolved ferrite in the interior of the rod, meanwhile the poor heat treatment causes the property differences between the surface and core structures of the rod, thus reduces the overall properties of fatigue- and corrosion-resistance. Stress corrosion makes pits from cracks; the expansion of such corrosion pits reduces the size of effective loading area; and the failure to endure service load due to the reduction of loading area finally causes sudden rupture of the rod.

• Periodical: Advanced Materials Research (Volumes 295-297)
• Pages: 626-630
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.295-297.626
• Online since: July 2011
• Authors: Yong Jun Bian, Wei Shi, Jin Yue Lao, Jie Chen, Shu Ling Sun
• Keywords: Crack, Fracture, Non-Metallic Inclusion, Segregation, Stress Corrosion, Sucker Rods

References

[1] Ren S; Zhang J; Chen, Z; et al. Atlas for steel metallography [M] (in Chinese).Shanghai: Shanghai Scientific and Technological Literature Publishing House Co., Ltd, 2005; p.702 Figure 11-49; p.744 Figure 12-23, p.738 Figure12-5, p.718 Figure 11-82; p.117 Figure 3-12; p.114 Figure3-5; p.64 Figure 2-63.

[2] First steel plant of Benxi Steel Co. Ltd; Tsinghua university; Overcooling austenite transition curve for steel[M] (in Chinese) Beijing : First Atlas 1978: pp.130-131.

[3] Wang H; Handbook for structural steel[M] (in Chinese) Shijiazhuang: Hebei Science and Technology Pres 1985, p.329.
