Influence of Annealing Temperature on the Structure and Electrochromic Properties of NiOx Thin Films

Article Preview

Abstract:

The NiOx thin flims deposited on SnO2/glass substrates by RF sputtering were investigated through XRD、SEM、spectrophotometer and Cyclic voltammetry. The relationship between electrochromic properties and micro-structure of NiOx was also studied. Results show that NiOx films prepared by sputtering are preferred to grow along (200) direction; the crystallize size of NiOx films increases and the transmittance of colored and bleached states of NiOx films also increases with annealing temperature rising, but the transmittance different between bleached and coloured states reduces. The declined electrochromic propertiey of NiOx with the increase of annealing temperature is also found.
