Comprehensive Dynamic Model and Vibration Characteristics of Step-Type Compound Planetary Gear Sets

Abstract:

Step-type compound planetary gear sets are widely applied in vehicle systems. Comprehensive dynamic model of step-type compound planetary gear sets, which includes translational, rotational vibrations and static transmission errors, was established. Natural vibration characteristics of the system, such as natural frequencies and vibration modes, were analyzed. Belt shape distribution characteristics of its natural frequencies was researched. According to vibration characteristics of both central components and planets, natural vibration modes of the system are classified into three types: central components translational vibration and planets random vibration, central components rotational vibration and planets identical vibration, central components static and adjacent planets reverse vibration mode.

• Periodical: Advanced Materials Research (Volumes 308-310)
• Pages: 1923-1928
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.308-310.1923
• Online since: August 2011
• Authors: Fu Chun Yang, Xiao Jun Zhou, Ming Xiang Xie
• Keywords: Compound Planetary Gear, Dynamic, Mode, Vibration

References

[1] Kahraman, A: Mechanism and machine theory Vol.36(2001), p.953.

[2] S.Dhouib, R. H., F.Chaari M.S. Abbes,T.Fakhfakh, M.Haddar, In: Proc. IMechE(2008), p.1389.

[3] Yang, F. Study on dynamic characteristics of compound planetary gear and wear mechanism of its thrust washer. Thesis of doctor's degree, Zhejiang University (2009). (In Chinese)

[4] Kiracofe, D. R., Parker, R. G: Transactions of the ASME Vol.129(2007), p.1.

[5] Lin J., P. R. G: Journal of vibration and acoustics Vol.121(1999), p.316.
