Dynamic Research on Vibration-Impact Crushing System of a Bilateral Single-Mass

Abstract:

The vibrating roller crusher convert relative vibration generated by two rigid bodies to bring high-frequency impulse on grain layer (or granular) in chamber, which makes grain crush to particle. Based on the science of vibration, dynamics model in vibration-impact crushing system of a bilateral single-mass and vibration differential equations are established. By dynamic analysis, amplitude frequency curve, hysteresis impact curve and energy absorption curve are all founded. The curves on dynamic response are discussed. Under the consideration of their results, displacement, velocity and acceleration with the time history are induced. Impact on the left and right sides are unsymmetrical. Influence laws on amplitude frequency, impact, energy absorption from clearance and vibration frequency is also established.

• Periodical: Advanced Materials Research (Volumes 308-310)
• Pages: 1914-1917
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.308-310.1914
• Online since: August 2011
• Authors: Su Huan Ni, Qing Guo Chen
• Keywords: A Bilateral Single-Mass, Amplitude Frequency, Dynamic, Energy Absorption, Impulse

References

[1] Decheng Dai. Nonlinear Oscillation. Publishing House of Southeast University, 1992:7-14(In Chinese)

[2] Shuying Liu, Qingkai Han, etc. Nonlinear dynamic analysis of New Vibrating Crusher. Journal of Vibration and Shock, 2000, 19(3)：34-36(In Chinese)

[3] Walter Lacarbonara, Fabrizio Vestroni. Nonclassical Responses of Oscillators with Hysteretic. Nonlinear Dynamics, 2003, 32:235-258
