The Efficiency and Experimental Investigation of Differential Gear Train

Abstract:

According to derive the efficiency formula of 2K-H differential gear train, the direction of meshing power has been determined. The test bench of fear train combination and structure analysis has been used to experimentation. The test results of various rotational speeds and torques have been collected by the dynamic load simulation loading. Through analyzing the test data, the efficiency formula of differential gear and its relationship with the dynamic load have been demonstrated. The results of experiment have been provided to experimental identification for the theories research

• Periodical: Advanced Materials Research (Volumes 308-310)
• Pages: 1893-1899
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.308-310.1893
• Online since: August 2011
• Authors: Chun Guo Zhou, Hui Wu Wang, Chao Feng Ma, Yan Guo
• Keywords: Differential Gear Train, Efficiency, Experiment

References

[1] Zhan Zhang, Hongsun Zhang, Xiaowei Zhang: Differential planet transmission device, Mechanical industry press (2009), p.12.

[2] Baoxian Jia, Wenfeng Bian: Mechanical design, Vol. 5 (1995), pp.33-36.

[3] Shiru Yang: Journal of Cheng du university, Vol. 20 (2001), pp.24-29.

[4] Qinhua Duan, Shiru Yang: Mechanical design, Vol. 1 (2001), pp.33-35.

[5] Qinhua Duan: Journal of Mechanical Transmission, Vol. 25 (2001), pp.30-33.

[6] Shuyan Wang: Mechanical Science and Technology, Vol. 19 (2001), pp.60-63.
