Dynamics Analysis of Gear Mesh of Transmission Based on Virtual Prototype

Abstract:

A commercial transmission provided by enterprise is analyzed in this paper. Its 3D model is established in UG software, its dynamic force and corresponding frequency diagram of constant mesh gear pair is analyzed in coupling mechanical system simulation(ADAMS). According to the result of analysis, the conclusion can provide basis for fatigue property, strength checking, structure optimization of gears and shafts, and noise abatement of global transmission. This method is an additional project for the stability, security of transmission products.

• Periodical: Advanced Materials Research (Volumes 308-310)
• Pages: 1910-1913
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.308-310.1910
• Online since: August 2011
• Authors: Jia Fu Wang, Xun Cheng Wu, Jing Tao Han
• Keywords: 3D Modeling, Dynamic Analysis, Gear Mesh, Virtual Prototype

References

[1] Zhenghao Ge: ADAMS2007 Virtual Prototype Technology (Chemical Industry Press, China 2010).

[2] Shiyi Zhao, Zijian Liu, Hui Wang: J. Computer Simulation Vol.23 (2006), p.200

[3] Wangyu Wang: Automobile Design The fourth edition (China Machine Press, China 2004).

[4] Chunsheng Li, Debing Huang: Material for Mechanical Engineering Handbook (Publishing House of Electronics Industry, China 2006).

[5] Rujin Hong: UG NX6 CAD Quickly Start Guide (Tsinghua University Press, China 2009).
