Brick Kiln Stacking-Destacking Robot Mechanism Design and Kinematics Analysis

Abstract:

This article describes the mechanical structure design method of the stacking-destacking robot and puts forward part kinematics analysis. In accordance with the actual technology requirement of modern brick kiln companies in logistics automation industry, a universal stacking-destacking robot is designed based on the functional requirement. And depending on the actual production requirements of the robot, it is designed to a kind of five-dof cylindrical coordinate one. This thesis focuses on the design and analysis of the mechanical structure of the robot. And according to the production requirements, some important components are selected. Finally, the kinematics analysis of the robot was brought forward and they are verified by experiments. The results show that this robot we designed can completely satisfy the technical requirements of the work in brick kilns destacking.

• Periodical: Advanced Materials Research (Volumes 308-310)
• Pages: 251-255
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.308-310.251
• Online since: August 2011
• Authors: Zheng Tao Zhang, Xiao Bo Liao
• Keywords: Five-DOF Cylindrical Coordinate Robot, Kinematics Analysis, Stacking-Destacking, Structure Design

References

[1] Yu XiaoMing Guan HuiSheng: Design of Four-Freedom Robot in Stack System and Research on It's Control System Performance (in Chinese ). SWJTU, (2008)

[2] Wu Zhenbiao el al: Optimum Design of Gripper for Handling Robot. Proceedings of ATEMH, (1994)

[3] H.H. Mabie and F.W. Ocvirk, in: Mechanisms and Dynamics of Machinery, John Wiley and Sons, NewYork(1978)..

[4] Southeast university machinery group, in: Principle of Mechanics, edited by Zheng Wenwei, Wu Kejian, Higher Education Press, Chinese (2000).

[5] Information on http://baike.baidu.com
