Development of Micro EDM with Directly Mounted APA 400MML Actuator as Tool Feed Mechanism

Abstract:

The development of new, advanced engineering materials and the need for precise flexible prototypes and low volume production have made Micro-EDM and important manufacturing process to meet such demands. The most important parameters in Micro-EDM are the material removal rate (MRR), the tool wear rate (TWR), accuracy and surface texture. The influence of peak current, gap voltage, pulse duration and process parameters plays important role in determining the material removal rate and tool wear rate on Micro EDM. Thus, this paper describes the development of the Micro-EDM based on the tool wear rate and material removal rate of the system using directly mounted APA 400MML actuator as the tool feed control system.

• Periodical: Advanced Materials Research (Volumes 314-316)
• Pages: 1811-1817
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.314-316.1811
• Online since: August 2011
• Authors: Samykano Mahendran, Ismail Fazli, Sawalingam Thinesh Chander
• Keywords: Advanced Machining Process, Electro Discharge Machining (EDM), Micro Machining, Micro-EDM, Non-Conventional Machining

References

[1] S. Mahendran, S. Thinesh Chaner and M. Hishammudin in: Analysis of Tool Wear in Micro EDM using Algor, Proceedings of Second National Conference in Mechanical Engineering for Research and Postgraduate Studies, (2010), pp.314-324

[2] Shabgard, Sadizadeh and Kakoulvand.in: The Effect of Ultrasonic Vibration of Workpiece in Electrical Discharge Machining of AISIH13 Tool Steel, World Academy of Science, Engineering and Technology, Vol. 52 (2009), pp.392-396

[2] Eberhard Bamberg and Sumet Heamawatanachai in: Orbital electrode actuation to improve efficiency of drilling micro-holes by micro-EDM, Journal of Materials Processing Technology, Vol. 209 (2009), p.1826–1834

DOI: 10.1016/j.jmatprotec.2008.04.044

[3] Sanjeev Kumar'Rupinder Singh, T.P Singh and B.L. Sethi in: Surface modification by electrical discharge machining: A review, Journal of Materials Processing Technology, Vol. 209 (2009), pp.3675-3687

DOI: 10.1016/j.jmatprotec.2008.09.032

[4] K. L. Wu, B. H. Yan, J-W. Lee and C. G. Ding in: Study on the characteristic of electrical discharge machining using surfactant, Journal of Material Processing Technology, Vol. 209(2009), pp.3783-3789

DOI: 10.1016/j.jmatprotec.2008.09.005

[5] B. B. Pradhan, G.Kibria and B.Bhattacharyya in: Modeling of Micro-EDM Process Parameters through Response Methodology, Competitive Manufacturing, Proceedings of the 2nd Intl. 23rd AIMTDR Conf, (2008), p.493

[6] Ho. K.H. and Newman, S.T. in: State of the art electrical discharge machining, International Journal of Machine Tools and Manufacture, Vol. 43 (2003), pp.1287-1300

DOI: 10.1016/s0890-6955(03)00162-7
