Research on the Forming Mechanism of Micro-Moulds Based on Laminated Slip-Welding of Ultrathin Stainless Steel Foils

Abstract:

To address the mainstream technology of UV-LIGA combined with micro-electroforming which could only fabricate micro-moulds cavity with vertical wall structure and low depth-to-width ratio, a new forming process based on femtosecond laser combined with laminated slip-welding was proposed in the paper. The forming process was achieved through experiment and it proved that the forming process could be a useful method for the process of micro-moulds with high depth-to-width ratio and complex structures. Work-pieces which were 0Cr18Ni9 stainless steel foils whose thickness was 20μm were welded by resistance welding machine and the microstructure of welding-zone was observed in detail. It was found that the welding-zone was composed of nugget zone, fusion zone and heat affected zone. Through the study of welding mechanism, the cooling rate of nugget zone was 3.99×104K/s and there was dynamic recrystallization in nugget zone. For further study, through the X-ray diffraction (XRD) test, it was found there were no chromium carbide and iron-copper eutectic alloy in nugget zone.

• Periodical: Advanced Materials Research (Volumes 314-316)
• Pages: 1818-1822
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.314-316.1818
• Online since: August 2011
• Authors: Bin Xu, Xiao Yu Wu, Feng Luo, Chen Lin Du, Xiu Quan Sun
• Keywords: Electric Resistance Welding, Femtosecond Laser, LOM, Micro-Moulds

References

[1] Yoshihiro Hirata: submitted to Nuclear Instruments and Methods in Physics Research (2003).

[2] F.Lermer, A.Urban: submitted to Microelectronic Engineering (2003).

[3] Wenmin Qu: submitted to Engineering Science and Education Journal (1999).

[4] Dongkeon Lee, Harutaka Mekaru, Hiroshi Hiroshima: submitted to Microsyst Technol (2010).

[5] Liqu Du, Shunpei Mo and Yusheng Zhang: submitted to Optics and Precision Engineering (2010) in Chinese.

[6] Jian Zhuang, Tongpin Yu and Minjie Wang: submitted to Journal of Harbin of Technology (2009) in Chinese.

[7] Shuping Yi, Fei Liu, Jin Zhang and Shiquan Xiong: submitted to Journal of Materials Processing Technology (2004).

[8] T. Nakagawa, M. Anzai: submitted to Optronics(1998).

[9] Erich Folkhard: Welding metallurgy of Stainless Steels (Springer-Verlag Wien New York, America 1987).

[10] Feng Xu, Jinfeng Xu and Qiuya Zhai: submitted to Transactions of the China Welding Institution (2009) in Chinese.
