Surface Channel Hot-Carrier Effect on CLC n-TFTs

Abstract:

The deterioration of continuous-wave green laser-crystallized (CLC) single-grainlike polycrystalline silicon n-channel thin-film transistors (poly-Si n-TFTs) under surface channel hot-carrier (CHC) stress (VDS=16 V and VGS=16 V labeled as a CHC-1 stress) was studied. The electrical properties of trap states containing interface trap states of gate oxide and poly-Si channel and grain boundary trap states were characterized by capacitance-voltage (C-V) measurement. In addition, while a higher stress voltage, CHC-2 stress at VDS=18 V and VGS=18 V, was adopted, the increase of interface trapped charges was obviously observed.

• Periodical: Advanced Materials Research (Volumes 314-316)
• Pages: 1881-1884
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.314-316.1881
• Online since: August 2011
• Authors: Mu Chun Wang, Hsin Chia Yang
• Keywords: Annealing, Channel Hot Carrier, CLC, Interface Trap States, Reliability, TFT

References

[1] J. H. Baek, et al.: IEEE Journal of Solid-State Circuits, vol.41, (2006), p.2974

[2] P. Barquinha, et al.: IEEE Electron Devices, vol.55, (2008), p.954

[3] J H Cheon, et al.: Electrochemical and Solid-State Letters, vol.10, (2007), p.155

[4] Dharam Pal Gosain, et al.: Jpn. J. Appl. Phys., vol.39, (2000), p.179

[5] Min Cao, et al.: IEEE Electron Devices, vol.43, (1996), p.561

[6] K. C. Moon, et al.: IEEE Electron Devices, vol.52, (2005),p.512

[7] Y. T. Lin, et al.: IEEE Electron Device Letters, vol.28, (2007), p.790

[8] J. M. Shieh,
et al.: Applied Physics Letters, vol.92, (2008), p.063503

[9] C. Hu: Modern Semiconductor Devices for Integrated Circuits (New Jersey 2010).

[10] G.A. Armstrong, et al.: IEEE Electron Device Letters, vol.18, (1997), p.315

[11] A. Khamesra, et al.: Proceedings of 8th IPFA, (2001), p.258
